The laboratory fridge comes with 1 drawer and 4 shelves as standard.
• PRO-ACTIVE- Control:
Permanent, proactive monitoring of the performance data and alerts in the case of deviations – so that you can take countermeasures in good time before a fault threatens your chilled goods; world´s most accurate temperature control in refrigerated areas thanks to two standard PT-1000 sensors
• 4 shelves, height- adjustable
• Re-circulating air cooling
• Warning in case of power failure (optical and acoustic)
• Optimized ventilation plates to minimize interior temperature differences
• Easy-to-read LED temperature display
• Automatical defrosting and melt water evaporation
• Easy accessible control panel with key switch
• Micro-processor controlled temperature and thawing regulation to maximize temperature stability
• Minimum/maximum temperature memory
• Safety device to prevent freezing
• Optical and acoustical alarm
• Data documentation can be read via USB interface with KIRSCH Datanet software.
• Potential free contact for alarm transmission
• Lockable door
Options
• Insulating glass door
• Lock for glass door
• Decorative frame
• Castors
• Additional s helves on mountings or telescopic runners
• Additional drawers on telescopic runners: max. 10 pieces
• Additional lenght and cross dividers for drawer
• LED illumination mounted at side wall
• Meltwater tray for manual emptying
• GSM-Module
• PC-KIT-NET (Network capable version)
• Pen-recording thermometer for placing loosely inside appliance with waxed paper strips
• Temperature probe PT 100 or PT 1000,
• 4 wire sensor, class 1/3 B, incl. measuring flask incorporated
Technical specifications
• Capacity: 330 l
• Temperature setting (approx.): +2 to +15 °C
• Voltage: 220 - 240 V
• Frequency: 50 Hz
• Power consumption: 110 Watts
• Average consumption: 0,65 KWh / 24 h
• Overall dimensions (incl. distance from wall): 67 x 69 x 181 (w x d x h in cm)
• Interior dimensions: 53 x 45 x 128 (w x d x h in cm)
• Overall dimensions with door opened at 90°: 67 x 127 (w x d in cm)
• Drawer inner dimensions: 50,4 x 32 x 5,6 (w x d x h in cm)
• Shelf dimensions: 53 x 39
• Max. loading capacity per drawer/shelf: 16 kg / 40 kg
• Weight: 88 kg / 100 kg (net / gross)

This laboratory fridge comes with 3 shelves as standard. The refrigerator can also be equipped with power failure alarm against surcharge.
• PRO-ACTIVE- Control:
Permanent, proactive monitoring of the performance data and alerts in the case of deviations – so that you can take countermeasures in good time before a fault threatens your chilled goods; world´s most accurate temperature control in refrigerated areas thanks to two standard PT-1000 sensors
• 3 shelves, height- adjustable
• Re-circulating air cooling
• Warning in case of power failure (optical and acoustic)
• Optimized ventilation plates to minimize interior temperature differences
• Easy-to-read LED temperature display
• Automatical defrosting and melt water evaporation
• Easy accessible control panel with key switch
• Micro-processor controlled temperature and thawing regulation to maximize temperature stability
• Minimum/maximum temperature memory
• Safety device to prevent freezing
• Optical and acoustical alarm
• Data documentation can be read via USB interface with KIRSCH Datanet software.
• Potential free contact for alarm transmission
• Lockable door
Options
• Decorative frame
• Glass door with lock
• 60 Hz cooling machine upon request
• Castors
• Door fitting
• Condensate container
• Plastic-drawer on roller runners
• Aluminium-drawer on roller runners
• Stainless steel-drawer
• Additional shelf on rails or overlays
• Additional lenght and cross dividers for drawer
• LED illumination mounted at side wall
• GSM-Module
• PC-KIT-NET (Network capable version)
• Pen-recording thermometer for placing loosely inside appliance with waxed paper strips
• Temperature probe PT 100 or PT 1000,
• 4 wire sensor, class 1/3 B, incl. measuring flask incorporated
Technical specifications
• Capacity 280 l
• Temperature setting (approx.) +2 to +15 °C
• Voltage : 220 - 240 V
• Frequency: 50 Hz
• Power consumption: 88 Watts
• Average consumption: 0,68 KWh / 24 h
• Overall dimensions (incl. distance from wall): 67 x 75 x 124 (w x d x h in cm)
• Interior dimensions: 53 x 50 x 100 (w x d x h in cm)
• Overall dimensions with door opened at 90°: 67 x 135 (w x d in cm)
• Shelf dimensions: 52 x 39 (w x d in cm)
• Max. loading capacity per drawer/shelf: 40 kg
• Weight: 78 kg / 85 kg (net / gross)

This laboratory refrigerator can be installed normally as well as in an undercounter installation. Door coupling fittings or decorative frames are available at an extra cost. When the device is being installed as a stand-alone unit we can optionally supply a matching tabletop.
• PRO-ACTIVE- Control:
• Permanent, proactive monitoring of the performance data and alerts in the case of deviations – so that you can take countermeasures in good time before a fault threatens your chilled goods; world´s most accurate temperature control in refrigerated areas thanks to two standard PT-1000 sensors
• 2 shelves
• Re-circulating air cooling
• Undercounter type
• Warning in case of power failure (optical and acoustic)
• Automatic defrosting
• Melt water evaporation
• Easy-to-read LED temperature display
• Automatical defrosting and melt water evaporation
• Easy accessible control panel with key switch
• Micro-processor controlled temperature and thawing regulation to maximize temperature stability
• Minimum/maximum temperature memory
• Safety device to prevent freezing
• Optical and acoustical alarm
• Data documentation can be read via USB interface with KIRSCH Datanet software.
• Potential free contact for alarm transmission
• Low-noise compressor (noise level I; sounds perception: whisper)
• Lockable door
Options
• Glass door with lock
• Work surface
• 60 Hz cooling machine upon request
• Decorative frame
• Door fitting
• Castors
• Additional shelf or drawer
• Additional length and cross dividers
• Melt water tray for manual emptying
• GSM-Module
• PC-KIT-NET (Network capable version)
• Pen-recording thermometer for placing loosely inside appliance with 2 waxed paper strips
• Temperature probe PT 100 or PT 1000, 4 wire sensor, class 1/3 B, incl. measuring flask incorporated
Technical Specifications
• Capacity 95 l
• Temperature setting (approx.) +2 to +15 °C
• Voltage 220 - 240 V
• Frequency 50 Hz
• Power consumption 76 Watts
• Average consumption 0,64 KWh / 24 h
• Overall dimensions
• (incl. distance from wall) 54 x 54 x 82 (w x d x h in cm)
• Interior dimensions 44 x 43 x 47 (w x d x h in cm)
• Overall dimensions with door
• opened at 90° 54 x 106 (w x d in cm)
• Drawer inner dimensions 40 x 32 x 5,6 (w x d x h in cm)
• Shelf dimensions 43 x 36 (w x d in cm)
• Max. loading capacity per drawer/shelf 13 kg / 25 kg
• Weight 46 kg / 50 kg (net / gross)

This laboratory fridge can be installed normally as well as in an undercounter installation. Door coupling fittings or decorative frames are available at an extra cost. The temperature display can optionally be installed in the front side of an external furniture. When the device is being installed as a stand-alone unit we can supply a matching tabletop at a surcharge.
Overview
• 2 shelves
• Undercounter type
• Automatic defrosting
• Melt water evaporation
• Digital temperature display
• Acoustic warning device
• Lockable door
Options
• Glass door
• Work surface
• Decorative frame
• Door fitting
• Castors
• Additional shelves: 43,8 x 33 cm
• Additional drawers: 40,8 x 32 x 5,6 cm
• Additional length and cross dividers
• Digital temperature display prepared for external installation
• Connecting terminal for remote alarm (potential free contact)
• Melt water tray for manual emptying
• GSM-Module
• Compressor ventilator installed, in case built-in furniture or handling with 60Hz version
• GSM-Module
• Pen-recording thermometer for placing loosely inside appliance with 2 waxed paper strips
• PT 100 or PT 1000 sensor for temperature recording and monitoring via EDP system
Technical specifications
• Capacity: 120 l
• Temperature setting (approx.): +2 to +15 °C
• Voltage: 220 - 240 V
• Frequeny: 50 Hz
• Power consumption: 125 Watts
• Average consumption: 0,55 KWh / 24 h
• Overall dimensions (incl. distance from wall): 54 x 53,5 x 81 (w x d x h in cm)
• Interior dimensions: 44 x 42 x 67 (w x d x h in cm)
• Overall dimensions with door opened at 90°: 54 x 106 (w x d in cm)
• Shelf dimensions: 43 x 33 (w x d in cm)
• Max. loading capacity per drawer/shelf : 13 kg / 25 kg
• Weight: 42 kg / 44 kg (net / gross)

Optimum level of comfort for the storage of flammable chemicals with 90 minutes of fire protection
• Width: 1194 mm
• Depth: 612 mm
• Height: 2085 mm
• Weight: 460 kg
• classical door technology (door handle) for the storage of flammable liquids
• type testing by MPA/TÜV SÜD according to DIN EN 14470-1, DIN EN 16121 and DIN EN 16122, EK5/AK4 09-10:2009 and AfPS GS 2014: 01 PAK mark of approval: GS/CE mark, high quality mark of approval by TÜV SÜD
Construction and colour:
• outer carcass sheet steel, RAL 7035
• doors sheet steel, RAL 1018
• inner carcass of decor panels, RAL 7035 fittings and features:
• doors close automatically in case of fire
• doors remain open in every position
• cylinder lock for safe access
• centre partition wall
• 2x 1 bottom tray sheet steel, RAL 7035
• 2x 3 pull-out shelves sheet steel, RAL 7035
• exhaust air connection socket on the cabinet roof
• visual inspection of the ventilation opening
• earthing connection on the cabinet roof
• interior fittings conductively connected with carcass
• adjustable foot for level adjustment

Optimum level of comfort for the storage of flammable chemicals with 90 minutes of fire protection
• Width: 1194 mm
• Depth: 612 mm
• Height: 2085 mm
• Weight: 467 kg
• one-hand door technology (door handle) for the storage of flammable liquids
• type testing by MPA/TÜV SÜD according to DIN EN 14470-1, DIN EN 16121 and DIN EN 16122, EK5/AK4 09-10:2009 and AfPS GS 2014: 01 PAK mark of approval: GS/CE mark, high quality mark of approval by TÜV SÜD
Construction and colour:
• outer carcass sheet steel, RAL 7035
• doors sheet steel, RAL 1018
• inner carcass of decor panels, RAL 7035 fittings and features:
• doors close automatically in case of fire
• doors remain open in every position
• cylinder lock for safe access
• centre partition wall
• 2x 1 bottom tray sheet steel, RAL 7035
• 2x 3 pull-out shelves sheet steel, RAL 7035
• exhaust air connection socket on the cabinet roof
• visual inspection of the ventilation opening
• earthing connection on the cabinet roof
• interior fittings conductively connected with carcass
• adjustable foot for level adjustment

Powerful and Convenient Mini Centrifuge for Simple and Rapid Life Science Separation Applications!
The OHAUS Frontier 5306 is a powerful mini centrifuge for simple and rapid liquid separation. The Frontier 5306 includes an 8-position 1.5/2 mL tube rotor as well as a 4-position 8-strip PCR tube rotor that can accommodate 32 individual PCR tubes or 0.2 mL strip tubes. With the included adapters, 0.2 mL and 0.5 mL strip tubes can also be accommodated in the 8 position tube rotor, further increasing its versatility. Frontier 5306 also has a quick release design in which the rotors can be removed and installed without the use of any tools. This centrifuge provides quiet, safe, and easy operation for your everyday quick spin-down applications.
Standard Features Include:
• A Quiet Motor and Rubber Base Assure Quiet Operation—With a low voltage power input, quiet motor, and rubber base that absorbs vibrati
• ons, Frontier 5306 keeps operational noise to a minimum and reduces disruptions in the laboratory.
• Multiple Protective Features Ensure the Safety of Centrifuge Operator—Frontier 5306 has many safety attributes, including a low voltage power input, sturdy lid, and two safety switches which immediately stop the rotors should the lid open while in rotation. An imbalance sensor also stops the centrifuge if the rotors become imbalanced or sudden shock occurs, protecting the operator from being injured by the high-speed spinning rotors.
• Simple One-Step Operation—Frontier 5306 takes simple operation to a new level. Once the device is powered on, simply place your sample in the centrifuge, close the lid, and it will begin to rotate. Not even one button press is needed in order to separate your sample.

Smooth and Dependable High-Speed Microliter Centrifuge for Liquid Separation Applications
Frontier 5515 and 5515R microliter benchtop centrifuges provide high-speed operation for spin-down applications requiring a wide variety of tube volumes and capacities. With refrigeration capabilities (FC5515R), 10 acceleration/deceleration settings, multiple safety features, and an unmatched capacity, Frontier provides stable liquid separation for applications requiring high-speed operation.
Standard Features Include
• Easy-to-Use Control Panel that Supports Simple Operation—The intuitive control panel with rotary knob puts the centrifuge’s simple operations at your fingertips, including the ability to set and recall speed and g-force, as well as control the temperature (FC5515R only).
• Sophisticated Technology that Drives High-Performance—A powerful brushless induction motor, 10 acceleration and deceleration settings, and memory for up to 99 commonly-used parameters are a few of Frontier’s features that propel high-performance.
• Safety Features that Protect Against Injury—Among Frontier’s safety attributes are a motorized lid locking system and a rotor imbalance sensor that stops the centrifuge if the rotors become imbalanced or sudden shock occurs, protecting the operator from the high-speed spinning rotors.
• Seven Rotor Sizes that Provide Flexibility for Varied Centrifugation Needs—Compatible with seven different rotors, more than any centrifuge in its class, the highly-versatile Frontier can be used for various applications of different volumes.

Compact Micro Centrifuge with Modern Touch-Wheel Interface Ideal for High-Speed Lab Applications
The FC5513 is a high-speed benchtop microliter centrifuge capable of generating 17,317 × g with four optional rotors, designed for a range of essential lab applications. Engineered with convenient operation in mind, the FC5513 features a uniquely designed splash-proof front panel with touchwheel control on an intuitive interface. The compact design saves valuable bench space in the lab.
Standard Features
• Select from a Variety of Rotors Designed for a Range of Lab Applications—The FC5513 offers standard 24 × 1.5/2 mL microtube rotors with a biocontainment option. This centrifuge can also support spin columns and hematocrit capillary tubes when used with additional rotor options.
• Modern Touch-Wheel Control on a Sleek Splash-Proof Interface—Designed for ease of operation, the FC5513 features convenient control on a protective splash-proof interface, which allows for responsive operation—even when wearing gloves.
• The Compact Design Saves Valuable Benchtop Space—Enclosing all its functionalities within a small footprint, the FC5513 saves valuable space on the lab bench.

Frontier™ Multi Centrifuges are reliable compact low-speed general purpose centrifuges. The standard rotor options can process both round and conical bottom tubes (including common blood tubes), and can also be adapted easily with accessories to process smaller tubes. Designed with convenient operation in mind, the Multi Centrifuges feature an intuitive interface. The compact profile helps to save valuable bench space in labs.
SPECIFICATIONS
• Speed Range: 200 rpm ; 6,800 rpm
• Maximum Relative Centrifuge Force: (x g) 4,445 g
• Maximum Capacity (Rotor): 8 x 15 ml
• Program memories: 99
• Rotor In Package Angle rotor: 8 x 15ml
• Acceleration Gear: 10
• Deceleration Gear: 10
• Dimensions (LxHxW): 14 in x 9.3 in x 10.9 in (356 mm x 236 mm x 277 mm)
• Display LCD with backlight
• Lid lock Mechanical
• Net Weight: 22.1 lb (10 kg)
• Noise Level: ≤60±2 dB(A)
• Power AC Power (Included)
• Power Consumption: 50 W
• Pre-cool time Not applicable
• Rotor Compatibility Angle: 8X15ml
• Rotor Recognition Method Manual
• Running Time Continous; Quickspin; 10 sec to 99 h 59 min 59 sec
• Safety Certification CE; FCC
• Working Environment 36°F – 95°F, 80%RH, non-condensing (2°C – 35°C, 80%RH, non-condensing)

Hei-VAP Expert Control
Adds numerous smart features to the Hei-VAP Expert, as well as an overview of all parameters and the current process
• 5" touch display for controlling the entire system including the vacuum and the cooling temperature
• For precise monitoring, the pictogram on the display also symbolizes active functions
• Separate knobs for quick access: the right one for direct vacuum control, the left one for the rotation
• Setting of values either via the touch display or the separate quick access knobs
• Direct access to two favorites on the start screen
• Expandable solvent library. You can also transfer your own favorites to other devices using a USB stick
• Define and save own evaporation processes (ramps)
• Automatically evaporate with the Dynamic AUTOaccurate Program (DAA). Convenient and customizable: from foam avoidance to highly efficient evaporation
• With USB and Micro SD interface for easy installation of software updates and transfer of individual favorites from one device to another
• Lift: Hand lift or Motor lift
• Rotation speed range: 10 - 280 rpm
• Rotation speed indicator: 5" LCD color graphic display
• Heating capacity: 1,300 W
• Overheat protection bath: cut-off at 5 °C over set temperature via separate PT 1000
• Bath temperature setting: 5" LCD color graphic display
• Heating bath temperature control: electronic / digital
• Max. size evaporating flask: 5 l
• Integrated vacuum controller: Yes
• Timer: Yes
• Integrated Hei-CHILL controller: Yes
• Vacuum program Dynamic AUTOaccurate
• requires AUTOaccurate sensor: Yes
• Programmable ramps: Yes
• Condensing surface: 1,400 cm²
• Condensing surface XL condenser: 2,200 cm²

Hei-VAP Expert Control
Adds numerous smart features to the Hei-VAP Expert, as well as an overview of all parameters and the current process
• 5" touch display for controlling the entire system including the vacuum and the cooling temperature
• For precise monitoring, the pictogram on the display also symbolizes active functions
• Separate knobs for quick access: the right one for direct vacuum control, the left one for the rotation
• Setting of values either via the touch display or the separate quick access knobs
• Direct access to two favorites on the start screen
• Expandable solvent library. You can also transfer your own favorites to other devices using a USB stick
• Define and save own evaporation processes (ramps)
• Automatically evaporate with the Dynamic AUTOaccurate Program (DAA). Convenient and customizable: from foam avoidance to highly efficient evaporation
• With USB and Micro SD interface for easy installation of software updates and transfer of individual favorites from one device to another
• Lift: Hand lift or Motor lift
• Rotation speed range: 10 - 280 rpm
• Rotation speed indicator: 5" LCD color graphic display
• Heating capacity: 1,300 W
• Overheat protection bath: cut-off at 5 °C over set temperature via separate PT 1000
• Bath temperature setting: 5" LCD color graphic display
• Heating bath temperature control: electronic / digital
• Max. size evaporating flask: 5 l
• Integrated vacuum controller: Yes
• Timer: Yes
• Integrated Hei-CHILL controller: Yes
• Vacuum program Dynamic AUTOaccurate
• requires AUTOaccurate sensor: Yes
• Programmable ramps: Yes
• Condensing surface: 1,400 cm²
• Condensing surface XL condenser: 2,200 cm²

Hei-VAP Expert Control
Adds numerous smart features to the Hei-VAP Expert, as well as an overview of all parameters and the current process
• 5" touch display for controlling the entire system including the vacuum and the cooling temperature
• For precise monitoring, the pictogram on the display also symbolizes active functions
• Separate knobs for quick access: the right one for direct vacuum control, the left one for the rotation
• Setting of values either via the touch display or the separate quick access knobs
• Direct access to two favorites on the start screen
• Expandable solvent library. You can also transfer your own favorites to other devices using a USB stick
• Define and save own evaporation processes (ramps)
• Automatically evaporate with the Dynamic AUTOaccurate Program (DAA). Convenient and customizable: from foam avoidance to highly efficient evaporation
• With USB and Micro SD interface for easy installation of software updates and transfer of individual favorites from one device to another
• Lift: Hand lift or Motor lift
• Rotation speed range: 10 - 280 rpm
• Rotation speed indicator: 5" LCD color graphic display
• Heating capacity: 1,300 W
• Overheat protection bath: cut-off at 5 °C over set temperature via separate PT 1000
• Bath temperature setting: 5" LCD color graphic display
• Heating bath temperature control: electronic / digital
• Max. size evaporating flask: 5 l
• Integrated vacuum controller: Yes
• Timer: Yes
• Integrated Hei-CHILL controller: Yes
• Vacuum program Dynamic AUTOaccurate
• requires AUTOaccurate sensor: Yes
• Programmable ramps: Yes
• Condensing surface: 1,400 cm²
• Condensing surface XL condenser: 2,200 cm²

Hei-VAP Expert Control
Adds numerous smart features to the Hei-VAP Expert, as well as an overview of all parameters and the current process
• 5" touch display for controlling the entire system including the vacuum and the cooling temperature
• For precise monitoring, the pictogram on the display also symbolizes active functions
• Separate knobs for quick access: the right one for direct vacuum control, the left one for the rotation
• Setting of values either via the touch display or the separate quick access knobs
• Direct access to two favorites on the start screen
• Expandable solvent library. You can also transfer your own favorites to other devices using a USB stick
• Define and save own evaporation processes (ramps)
• Automatically evaporate with the Dynamic AUTOaccurate Program (DAA). Convenient and customizable: from foam avoidance to highly efficient evaporation
• With USB and Micro SD interface for easy installation of software updates and transfer of individual favorites from one device to another
• Lift: Hand lift or Motor lift
• Rotation speed range: 10 - 280 rpm
• Rotation speed indicator: 5" LCD color graphic display
• Heating capacity: 1,300 W
• Overheat protection bath: cut-off at 5 °C over set temperature via separate PT 1000
• Bath temperature setting: 5" LCD color graphic display
• Heating bath temperature control: electronic / digital
• Max. size evaporating flask: 5 l
• Integrated vacuum controller: Yes
• Timer: Yes
• Integrated Hei-CHILL controller: Yes
• Vacuum program Dynamic AUTOaccurate
• requires AUTOaccurate sensor: Yes
• Programmable ramps: Yes
• Condensing surface: 1,400 cm²
• Condensing surface XL condenser: 2,200 cm²

Hei-VAP Expert Control
Adds numerous smart features to the Hei-VAP Expert, as well as an overview of all parameters and the current process
• 5" touch display for controlling the entire system including the vacuum and the cooling temperature
• For precise monitoring, the pictogram on the display also symbolizes active functions
• Separate knobs for quick access: the right one for direct vacuum control, the left one for the rotation
• Setting of values either via the touch display or the separate quick access knobs
• Direct access to two favorites on the start screen
• Expandable solvent library. You can also transfer your own favorites to other devices using a USB stick
• Define and save own evaporation processes (ramps)
• Automatically evaporate with the Dynamic AUTOaccurate Program (DAA). Convenient and customizable: from foam avoidance to highly efficient evaporation
• With USB and Micro SD interface for easy installation of software updates and transfer of individual favorites from one device to another
• Lift: Hand lift or Motor lift
• Rotation speed range: 10 - 280 rpm
• Rotation speed indicator: 5" LCD color graphic display
• Heating capacity: 1,300 W
• Overheat protection bath: cut-off at 5 °C over set temperature via separate PT 1000
• Bath temperature setting: 5" LCD color graphic display
• Heating bath temperature control: electronic / digital
• Max. size evaporating flask: 5 l
• Integrated vacuum controller: Yes
• Timer: Yes
• Integrated Hei-CHILL controller: Yes
• Vacuum program Dynamic AUTOaccurate
• requires AUTOaccurate sensor: Yes
• Programmable ramps: Yes
• Condensing surface: 1,400 cm²
• Condensing surface XL condenser: 2,200 cm²

Hei-VAP Expert Control
Adds numerous smart features to the Hei-VAP Expert, as well as an overview of all parameters and the current process
• 5" touch display for controlling the entire system including the vacuum and the cooling temperature
• For precise monitoring, the pictogram on the display also symbolizes active functions
• Separate knobs for quick access: the right one for direct vacuum control, the left one for the rotation
• Setting of values either via the touch display or the separate quick access knobs
• Direct access to two favorites on the start screen
• Expandable solvent library. You can also transfer your own favorites to other devices using a USB stick
• Define and save own evaporation processes (ramps)
• Automatically evaporate with the Dynamic AUTOaccurate Program (DAA). Convenient and customizable: from foam avoidance to highly efficient evaporation
• With USB and Micro SD interface for easy installation of software updates and transfer of individual favorites from one device to another
• Lift: Hand lift or Motor lift
• Rotation speed range: 10 - 280 rpm
• Rotation speed indicator: 5" LCD color graphic display
• Heating capacity: 1,300 W
• Overheat protection bath: cut-off at 5 °C over set temperature via separate PT 1000
• Bath temperature setting: 5" LCD color graphic display
• Heating bath temperature control: electronic / digital
• Max. size evaporating flask: 5 l
• Integrated vacuum controller: Yes
• Timer: Yes
• Integrated Hei-CHILL controller: Yes
• Vacuum program Dynamic AUTOaccurate
• requires AUTOaccurate sensor: Yes
• Programmable ramps: Yes
• Condensing surface: 1,400 cm²
• Condensing surface XL condenser: 2,200 cm²

Hei-VAP Expert Control
Adds numerous smart features to the Hei-VAP Expert, as well as an overview of all parameters and the current process
• 5" touch display for controlling the entire system including the vacuum and the cooling temperature
• For precise monitoring, the pictogram on the display also symbolizes active functions
• Separate knobs for quick access: the right one for direct vacuum control, the left one for the rotation
• Setting of values either via the touch display or the separate quick access knobs
• Direct access to two favorites on the start screen
• Expandable solvent library. You can also transfer your own favorites to other devices using a USB stick
• Define and save own evaporation processes (ramps)
• Automatically evaporate with the Dynamic AUTOaccurate Program (DAA). Convenient and customizable: from foam avoidance to highly efficient evaporation
• With USB and Micro SD interface for easy installation of software updates and transfer of individual favorites from one device to another
• Lift: Hand lift or Motor lift
• Rotation speed range: 10 - 280 rpm
• Rotation speed indicator: 5" LCD color graphic display
• Heating capacity: 1,300 W
• Overheat protection bath: cut-off at 5 °C over set temperature via separate PT 1000
• Bath temperature setting: 5" LCD color graphic display
• Heating bath temperature control: electronic / digital
• Max. size evaporating flask: 5 l
• Integrated vacuum controller: Yes
• Timer: Yes
• Integrated Hei-CHILL controller: Yes
• Vacuum program Dynamic AUTOaccurate
• requires AUTOaccurate sensor: Yes
• Programmable ramps: Yes
• Condensing surface: 1,400 cm²
• Condensing surface XL condenser: 2,200 cm²

Hei-VAP Expert Control
Adds numerous smart features to the Hei-VAP Expert, as well as an overview of all parameters and the current process
• 5" touch display for controlling the entire system including the vacuum and the cooling temperature
• For precise monitoring, the pictogram on the display also symbolizes active functions
• Separate knobs for quick access: the right one for direct vacuum control, the left one for the rotation
• Setting of values either via the touch display or the separate quick access knobs
• Direct access to two favorites on the start screen
• Expandable solvent library. You can also transfer your own favorites to other devices using a USB stick
• Define and save own evaporation processes (ramps)
• Automatically evaporate with the Dynamic AUTOaccurate Program (DAA). Convenient and customizable: from foam avoidance to highly efficient evaporation
• With USB and Micro SD interface for easy installation of software updates and transfer of individual favorites from one device to another
• Lift: Hand lift or Motor lift
• Rotation speed range: 10 - 280 rpm
• Rotation speed indicator: 5" LCD color graphic display
• Heating capacity: 1,300 W
• Overheat protection bath: cut-off at 5 °C over set temperature via separate PT 1000
• Bath temperature setting: 5" LCD color graphic display
• Heating bath temperature control: electronic / digital
• Max. size evaporating flask: 5 l
• Integrated vacuum controller: Yes
• Timer: Yes
• Integrated Hei-CHILL controller: Yes
• Vacuum program Dynamic AUTOaccurate
• requires AUTOaccurate sensor: Yes
• Programmable ramps: Yes
• Condensing surface: 1,400 cm²
• Condensing surface XL condenser: 2,200 cm²

Hei-VAP Expert Control
Adds numerous smart features to the Hei-VAP Expert, as well as an overview of all parameters and the current process
• 5" touch display for controlling the entire system including the vacuum and the cooling temperature
• For precise monitoring, the pictogram on the display also symbolizes active functions
• Separate knobs for quick access: the right one for direct vacuum control, the left one for the rotation
• Setting of values either via the touch display or the separate quick access knobs
• Direct access to two favorites on the start screen
• Expandable solvent library. You can also transfer your own favorites to other devices using a USB stick
• Define and save own evaporation processes (ramps)
• Automatically evaporate with the Dynamic AUTOaccurate Program (DAA). Convenient and customizable: from foam avoidance to highly efficient evaporation
• With USB and Micro SD interface for easy installation of software updates and transfer of individual favorites from one device to another
• Lift: Hand lift or Motor lift
• Rotation speed range: 10 - 280 rpm
• Rotation speed indicator: 5" LCD color graphic display
• Heating capacity: 1,300 W
• Overheat protection bath: cut-off at 5 °C over set temperature via separate PT 1000
• Bath temperature setting: 5" LCD color graphic display
• Heating bath temperature control: electronic / digital
• Max. size evaporating flask: 5 l
• Integrated vacuum controller: Yes
• Timer: Yes
• Integrated Hei-CHILL controller: Yes
• Vacuum program Dynamic AUTOaccurate
• requires AUTOaccurate sensor: Yes
• Programmable ramps: Yes
• Condensing surface: 1,400 cm²
• Condensing surface XL condenser: 2,200 cm²

Hei-VAP Expert Control
Adds numerous smart features to the Hei-VAP Expert, as well as an overview of all parameters and the current process
• 5" touch display for controlling the entire system including the vacuum and the cooling temperature
• For precise monitoring, the pictogram on the display also symbolizes active functions
• Separate knobs for quick access: the right one for direct vacuum control, the left one for the rotation
• Setting of values either via the touch display or the separate quick access knobs
• Direct access to two favorites on the start screen
• Expandable solvent library. You can also transfer your own favorites to other devices using a USB stick
• Define and save own evaporation processes (ramps)
• Automatically evaporate with the Dynamic AUTOaccurate Program (DAA). Convenient and customizable: from foam avoidance to highly efficient evaporation
• With USB and Micro SD interface for easy installation of software updates and transfer of individual favorites from one device to another
• Lift: Hand lift or Motor lift
• Rotation speed range: 10 - 280 rpm
• Rotation speed indicator: 5" LCD color graphic display
• Heating capacity: 1,300 W
• Overheat protection bath: cut-off at 5 °C over set temperature via separate PT 1000
• Bath temperature setting: 5" LCD color graphic display
• Heating bath temperature control: electronic / digital
• Max. size evaporating flask: 5 l
• Integrated vacuum controller: Yes
• Timer: Yes
• Integrated Hei-CHILL controller: Yes
• Vacuum program Dynamic AUTOaccurate
• requires AUTOaccurate sensor: Yes
• Programmable ramps: Yes
• Condensing surface: 1,400 cm²
• Condensing surface XL condenser: 2,200 cm²
