Description
For the monitoring of your vacuum processes in the rough and fine vacuum range, the new vacuum gauges VACUU•VIEW extended are perfect! The heavy duty combination of ceramic diaphragm sensor and ceramic jacketed Pirani sensor ensures reliable readings in the wide range from atmosphere down to 10-3 mbar.
Performance features
• Precision and chemical resistance in an exceptionally wide range from atmosphere down to 10-3 mbar, one gauge only for both rough and fine vacuum
• compact design with integrated sensors for useful setup in laboratory and process
• the chemical resistant combination of ceramic diaphragm sensor and ceramic jacketed Pirani sensor ensures a long product life even with aggressive chemicals
• illuminated display, easy to read
• display with menu driven handling, easy to use e.g. for unit settings

Screw pump for aggressive gases and vapors
The dry screw pump VACUU•PURE® 10C reliably delivers the benefits of oil-free vacuum technology in the pressure range of 10-3 mbar. The new vacuum pump combines three important benefits for the user: 100% oil-free, chemically resistant, and no wear parts.
VACUU•PURE 10C is ideally suited for clean processes and the production of pure products. The screw pump is especially designed for processes in the vacuum range down to 10-3 mbar, however unlike other fine vacuum technologies it can be used across the entire pressure range from atmospheric pressure to its ultimate vacuum. At the same time, aggressive gases and vapors can be pumped without any worries because of the high chemical resistance. The use of a cold trap is no longer necessary in the majority of applications.
VACUU•PURE easily handles high vapor loads through its extraordinary condensate compatibility. Thanks to this capability, a gas ballast is unnecessary, avoiding associated disadvantages like the reduction in pumping speed and an increase in noise levels. The integrated regeneration mode enables rapid drying of the pump at the end of the process. This allows sample throughput to be increased significantly as compared to other pump technologies.
For work performed with non-corrosive gases and vapors, there is the specially designed model VACUU•PURE 10.

Screw pump for non-corrosive applications
The dry screw pump VACUU•PURE® 10 reliably delivers the benefits of oil-free vacuum technology in the pressure range down to 10-3 mbar. VACUU•PURE 10 combines three important benefits for the user: 100% oil-free, no abrasion, and no wear parts.
VACUU•PURE 10 is ideal for clean processes which require a dry and hydrocarbon-free vacuum. The spindles of the screw pump run contact-free and are thus free of abrasion and wear. The screw pump is especially designed for processes in the vacuum range down to 10-3 mbar, however unlike other fine vacuum technologies it can be used across the entire pressure range from atmospheric pressure to its ultimate vacuum. The evacuation of even larger systems from atmospheric pressure down to the 10-3 mbar vacuum range can be done without changing the vacuum pump.
VACUU•PURE easily handles high levels of vapor accumulation through its extraordinary condensate compatibility. Thanks to this capability, a gas ballast is unnecessary, avoiding associated disadvantages like the reduction in pumping speed and an increase in noise levels. The integrated regeneration mode enables rapid drying of the pump at the end of the process. This allows sample throughput to be increased significantly as compared to other pump technologies.
VACUU•PURE is also available in a chemically resistant design for working with aggressive gases and vapors.

Description
With the new ATEX VARIO® chemistry diaphragm pumps and vacuum systems, the vacuum can be precisely controlled by the motor speed. The VARIO® pump is driven by an additional control signal line. The optional vacuum controller CVC 3000 with system accessories (I/O-Module, supply / isolation amplifier) and ATEX vacuum sensor enable fully automatic evaporations without the need for parameter settings or user programming. With the adaptive control it finds the boiling pressure independently and adjusts the vacuum continuously and optimally according to the vapor pressure.
The vacuum controller and system accessories are installed in a non-hazardous area.
Performance features
• full advantage of ATEX chemistry diaphragm pumps with separator AK and emission condenser EK
• VARIO®: short process times due to hysteresis-free VARIO® vacuum control
• VARIO®: VARIO® pump operates on demand only as fast as necessary – minimal power consumption, extended maintenance intervals, silent operation
• VARIO®: vacuum controller CVC 3000 (optional) for precise vacuum control and fully automatic processes
• complete system accessories I/O module, isolation amplifier and ATEX vacuum sensor - from one source

Description
With the new ATEX VARIO® chemistry diaphragm pumps and vacuum systems, the vacuum can be precisely controlled by the motor speed. The VARIO® pump is driven by an additional control signal line. The optional vacuum controller CVC 3000 with system accessories (I/O-Module, supply / isolation amplifier) and ATEX vacuum sensor enable fully automatic evaporations without the need for parameter settings or user programming. With the adaptive control it finds the boiling pressure independently and adjusts the vacuum continuously and optimally according to the vapor pressure.
The vacuum controller and system accessories are installed in a non-hazardous area.
Performance features
• full advantage of ATEX chemistry diaphragm pumps
• VARIO®: short process times due to hysteresis-free VARIO® vacuum control
• VARIO®: VARIO® pump operates on demand only as fast as necessary – minimal power consumption, extended maintenance intervals, silent operation
• VARIO®: Vacuum controller CVC 3000 (optional) for precise vacuum control and fully automatic processes
• complete system accessories I/O module, supply / isolation amplifier and ATEX vacuum sensor

Description
With the new ATEX VARIO® chemistry diaphragm pumps and vacuum systems, the vacuum can be precisely controlled by the motor speed. The VARIO® pump is driven by an additional control signal line. The optional vacuum controller CVC 3000 with system accessories (I/O-Module, supply / isolation amplifier) and ATEX vacuum sensor enable fully automatic evaporations without the need for parameter settings or user programming. With the adaptive control it finds the boiling pressure independently and adjusts the vacuum continuously and optimally according to the vapor pressure.
The vacuum controller and system accessories are installed in a non-hazardous area.
Performance features
• full advantage of ATEX chemistry diaphragm pumps with separator AK and emission condenser EK
• VARIO®: short process times due to hysteresis-free VARIO® vacuum control
• VARIO®: VARIO®-pump operates on demand only as fast as necessary – minimal power consumption, extended maintenance intervals, silent operation
• VARIO®: Vacuum controller CVC 3000 (optional) for precise vacuum control and fully automatic processes
• complete system accessories I/O module, supply / isolation amplifier and ATEX vacuum sensor - from one source

Description
With the new ATEX VARIO® chemistry diaphragm pumps and vacuum systems, the vacuum can be precisely controlled by the motor speed. The VARIO® pump is driven by an additional control signal line. The optional vacuum controller CVC 3000 with system accessories (I/O-Module, supply / isolation amplifier) and ATEX vacuum sensor enable fully automatic evaporations without the need for parameter settings or user programming. With the adaptive control it finds the boiling pressure independently and adjusts the vacuum continuously and optimally according to the vapor pressure.
The vacuum controller and system accessories are installed in a non-hazardous area.
Performance features
• full advantage of ATEX chemistry diaphragm pumps
• VARIO®: short process times due to hysteresis-free VARIO® vacuum control
• VARIO®: VARIO®-pump operates on demand only as fast as necessary – minimal power consumption, extended maintenance intervals, silent operation
• VARIO®: vacuum controller CVC 3000 (optional) for precise vacuum control and fully automatic processes
• complete system accessories I/O module, supply / isolation amplifier and ATEX vacuum sensor - from one source

Description
ATEX chemistry diaphragm pumps offer all advantages of oil-free chemistry diaphragm pumps. Typical applications are rotary evaporators and drying ovens with potentially explosive atmospheres. The ATEX approval includes the interior of the pump (in contact with pumped gases) as well as the surrounding area of the pump. All wetted parts of the pumps have excellent chemical resistance and are mainly made of antistatic materials. Included in delivery is a separate gas ballast connection part for use of inert gas.
Performance features
• outstanding chemical resistance and superior vapor tolerance
• flame proof motor with integrated, self-locking overload and excess temperature protection for direct 230V / 50Hz single phase power supply. No need for any additional and specific overcurrent protection device
• overpressure safety relief valves internally and at outlet
• safety diaphragm technology with option for inert gas purge and detection of diaphragm breakage

Description
ATEX chemistry vacuum systems are ready for use for applications with large amounts of condensable vapors due to optimally configured accessories. Typical applications are rotary evaporators and drying ovens with potentially explosive atmospheres. The separator at the inlet (AK) retains particles and liquid droplets. The waste vapor condenser at the outlet (EK) is highly efficient and compact. The condenser enables near-100-percent solvent recovery. Included in delivery is a separate gas ballast connection part for use with inert gas.
Performance features
• outstanding chemical resistance and superior vapor tolerance
• flame proof motor with integrated, self-locking overload and excess temperature protection for direct 230V / 50Hz single phase power supply. No need for any additional and specific overcurrent protection device
• overpressure safety relief valves internally and at outlet
• safety diaphragm technology with option for inert gas purge and detection of diaphragm breakage
• separator AK and emission condenser EK for pump protection and solvent recovery

Description
ATEX chemistry diaphragm pumps offer all advantages of oil-free chemistry diaphragm pumps. Typical applications are rotary evaporators and drying ovens with potentially explosive atmospheres. The ATEX approval includes the interior of the pump (in contact with pumped gases) as well as the surrounding area of the pump. All wetted parts of the pumps have excellent chemical resistance and are mainly made of antistatic materials. Included in delivery is a separate gas ballast connection part for use of inert gas.
Performance features
• outstanding chemical resistance and superior vapor tolerance
• flame proof motor with integrated, self-locking overload and excess temperature protection for direct 230V / 50Hz single phase power supply. No need for any additional and specific overcurrent protection device
• overpressure safety relief valves internally and at outlet
• safety diaphragm technology with option for inert gas purge and detection of diaphragm breakage

Description
ATEX chemistry vacuum systems are ready for use for applications with large amounts of condensable vapors due to optimally configured accessories. Typical applications are rotary evaporators and drying ovens with potentially explosive atmospheres. The separator at the inlet (AK) retains particles and liquid droplets. The waste vapor condenser at the outlet (EK) is highly efficient and compact. The condenser enables near-100-percent solvent recovery. Included in delivery is a separate gas ballast connection part for use with inert gas.
Performance features
• outstanding chemical resistance and superior vapor tolerance
• flame proof motor with integrated, self-locking overload and excess temperature protection for direct 230V / 50Hz single phase power supply. No need for any additional and specific overcurrent protection device
• overpressure safety relief valves internally and at outlet
• safety diaphragm technology with option for inert gas purge and detection of diaphragm breakage
• separator AK and emission condenser EK for pump protection and solvent recovery

Description
ATEX chemistry diaphragm pumps offer all advantages of oil-free chemistry diaphragm pumps. Typical applications are rotary evaporators and drying ovens with potentially explosive atmospheres. The ATEX approval includes the interior of the pump (in contact with pumped gases) as well as the surrounding area of the pump. All wetted parts of the pumps have excellent chemical resistance and are mainly made of antistatic materials. Included in delivery is a separate gas ballast connection part for use of inert gas.
Performance features
• outstanding chemical resistance and superior vapor tolerance
• flame proof motor with integrated, self-locking overload and excess temperature protection for direct 230V / 50Hz single phase power supply. No need for any additional and specific overcurrent protection device
• overpressure safety relief valves internally and at outlet
• safety diaphragm technology with option for inert gas purge and detection of diaphragm breakage

Description
Four-stage diaphragm pumps are an excellent solution for continuous, oil-free pumping of gases when the need is to reach fractional millibar ultimate vacuums. All parts in contact with pumped vapors or gases are made of aluminum, stainless steel and carefully selected plastics suitable for a wide range of non-corrosive applications. These pumps provide the advantageous combination of high pumping speed with an extraordinary good ultimate vacuum down to 0.5 mbar. The highly flexible, fabric-reinforced double diaphragms made of FKM offer extended operating life. Eight-cylinder NT pumps features quiet operation, smooth and easy to clean surfaces.
Performance features
• contamination-free pumping and evacuation
• high performance even close to the excellent ultimate vacuum
• whisper quiet
• very low vibration
• exceptionally long diaphragm life and maintenance-free drive system for low lifetime costs

Description
Four-stage diaphragm pumps are an excellent solution for continuous, oil-free pumping of gases when the need is to reach fractional millibar ultimate vacuums. All parts in contact with pumped vapors or gases are made of aluminum, stainless steel and carefully selected plastics suitable for a wide range of non-corrosive applications. The new NT-series pumps provide whisper-quiet and ultra-low-vibration operation, high leak-tightness and improved vacuum. The highly flexible, fabric-reinforced double diaphragm made of FKM offers extended operating life.
Performance features
• contamination-free pumping and evacuation
• high flow rate even near ultimate vacuum
• outstanding ultimate vacuum
• whisper quiet and ultra-low vibration
• exceptionally long diaphragm life and maintenance-free drive system for low lifetime costs

Description
The MD 12 NT diaphragm pump is an especially powerful pump for oil-free evacuation and pumping of non aggressive gases. The three-stage design of this eight-cylinder pump provides the advantageous combination of very high pumping speed and excellent ultimate vacuum. The flow path consists of aluminium, stainless steel and carefully selected plastics to permit a wide range of applications. The fabric-reinforced double diaphragms are made of highly flexible FKM for extended operating life and high vacuum performance. Eight-cylinder NT pumps feature quiet operation, with smooth and easy-to-clean surfaces. Like all VACUUBRAND diaphragm pumps they operate absolutely oil-free and do not have any sliding components in the gas path. In normal operation they are completely free of abrasion. This eliminates most of the particulate impurities frequently generated inside of scroll or piston pumps.
Performance features
• contamination-free pumping and evacuation
• high flow rate even near ultimate vacuum
• whisper quiet
• reduced process times
• exceptionally long diaphragm life and maintenance-free drive system for low lifetime costs

Description
These three-stage diaphragm pumps are an excellent solution for continuous, oil-free pumping of non-corrosive gases. They reach an excellent ultimate vacuum of 1 mbar. All parts in contact with pumped gases and vapors are made of aluminum, stainless steel and carefully selected plastics suitable for a wide range of applications with non-corrosive gases. The new NT-series provides whisper quiet and ultra-low vibration operation, high leak tightness and improved performance. The highly flexible fabric-reinforced double diaphragm made of FKM is ideal for extended operating life.

Performance features
contamination-free pumping and evacuation
high flow rate even near ultimate vacuum
whisper quiet
very low vibration
exceptionally long diaphragm life and maintenance-free drive system for low lifetime cost

Description
The MD 1 diaphragm pump is an excellent choice for oil-free evacuation and pumping of non-corrosive gases down to 1.5 mbar ultimate vacuum. The three-stage design with precisely guided flat diaphragms provides outstanding pumping speed even close to the ultimate vacuum, especially when compared with similarly rated two-stage diaphragm pumps. The MD 1 is an ultra-low vibration pump with very long diaphragm lilfetime and stable ultimate vacuum documented with years of testing. With a flow path consisting of aluminum and selected plastics (diaphragms and valves made of PTFE/FKM and FKM, respectively) the pumps are suitable for a wide range of applications with non-corrosive gases.
Performance features
• contamination-free pumping and evacuation
• high flow rate even near ultimate vacuum
• excellent ultimate vacuum
• whisper quiet and ultra-low vibration
• proven long diaphragm life, maintenance-free drive system

Description
Diaphragm pumps are an excellent solution for continuous, oil-free evacuation and pumping of gases. All parts in these MZ 2 series pumps that are in contact with pumped media are made of aluminum, stainless steel and selected plastics, allowing a wide range of applications for non-corrosive gases. The two-stage construction provides the advantageous combination of high pumping speed and an ultimate vacuum down to 4 mbar. The highly flexible fabric-reinforced double diaphragms made of FKM provide high reliability and extended operating life. The NT-series features further improved performance data and compact design.
Performance features
• contamination-free pumping and evacuation
• high flow rate even near ultimate vacuum
• good ultimate vacuum
• whisper quiet and very low vibration
• exceptionally long diaphragm life and maintenance-free drive system for low lifetime costs

Description
Diaphragm pumps are an excellent solution for continuous, oil-free evacuation and pumping of gases. All parts in contact with pumped media are made of aluminum and selected plastics and allow a wide range of applications for non corrosive gases. The two-stage construction provides the advantageous combination of high pumping speed and an ultimate vacuum down to 7 mbar. The highly flexible fabric-reinforced double diaphragm made of FKM is ideal for extended operating life. The new NT-series features further improved performance data.
Performance features
• contamination-free pumping and evacuation
• high flow rate even near ultimate vacuum
• whisper quiet
• very low vibration
• exceptionally long diaphragm life and maintenance-free drive system for low lifetime costs

Description
Diaphragm pumps are an excellent solution for continuous, oil-free evacuation and pumping of gases. The one-stage design provides the advantageous combination of high pumping speed and low ultimate vacuum down to 70 mbar. All parts in contact with pumped media are made of aluminum and selected plastics allowing a wide range of applications for non-corrosive gases. The highly flexible, fabric-reinforced double diaphragms made of FKM are ideal for extended operating life. These pumps are particularly powerful and offer large volume flow. The eight-cylinder pump ME 16 NT features exceptionally high pumping speed, low vibration and a very compact design with smooth and easy-to-clean surfaces.
Performance features
• contamination-free pumping and evacuation
• high flow rate even near ultimate vacuum
• whisper quiet
• very low vibration
• exceptionally long diaphragm life and maintenance-free drive system for low lifetime costs
