With the new ATEX VARIO® chemistry diaphragm pumps and vacuum systems, the vacuum can be precisely controlled by the motor speed. The VARIO® pump is driven by an additional control signal line. The optional vacuum controller CVC 3000 with system accessories (I/O-Module, supply / isolation amplifier) and ATEX vacuum sensor enable fully automatic evaporations without the need for parameter settings or user programming. With the adaptive control it finds the boiling pressure independently and adjusts the vacuum continuously and optimally according to the vapor pressure.
The vacuum controller and system accessories are installed in a non-hazardous area.

Performance features
• full advantage of ATEX chemistry diaphragm pumps with separator AK and emission condenser EK
• VARIO®: short process times due to hysteresis-free VARIO® vacuum control
• VARIO®: VARIO® pump operates on demand only as fast as necessary – minimal power consumption, extended maintenance intervals, silent operation
• VARIO®: vacuum controller CVC 3000 (optional) for precise vacuum control and fully automatic processes
• complete system accessories I/O module, isolation amplifier and ATEX vacuum sensor - from one source

ATEX chemistry vacuum systems are ready for use for applications with large amounts of condensable vapors due to optimally configured accessories. Typical applications are rotary evaporators and drying ovens with potentially explosive atmospheres. The separator at the inlet (AK) retains particles and liquid droplets. The waste vapor condenser at the outlet (EK) is highly efficient and compact. The condenser enables near-100-percent solvent recovery. Included in delivery is a separate gas ballast connection part for use with inert gas.
ATEX conformity: Pumping chamber (pumped gases): II 2G Ex h IIC T3 Gb X, Environment with inert purge gas: II 2G Ex h IIB T4 Gb X, Environment without inert purge gas: II 3G Ex h IIB T4 Gc X, Motor: II 2G Ex db IIB T4 Gb

Features
• Outstanding chemical resistance and superior vapor tolerance
• Flame proof motor with integrated, self-locking overload and excess temperature protection for direct 230V / 50Hz single phase power supply. No
• Need for any additional and specific overcurrent protection device
• Overpressure safety relief valves internally and at outlet
• Safety diaphragm technology with option for inert gas purge and detection of diaphragm breakage
• Separator AK and emission condenser EK for pump protection and solvent recovery

Technical data:
• Ultimate vacuum with gas ballast: 10 mbar
• Number of heads: 8
• Number of stages: 4

For Single- and Multi-Channel use (not suitable with cassette small)
• Application: For standard applications
Features:
• Non-toxic, non-oxidizing
• Good resistance to acids, bases and inorganic media
• Very low gas permeability, good performance life
• Material: Thermoplastic soft PVC, transparent
• Complies with the standards: FDA (21 CFR 177.2601) and GLP
• Temperature range: -50 to +75 °C
• Sterilization: Can be autoclaved for 30 min at 1 bar and 120 °C (material may change color) or with ethylene oxide
• Restriction: Segregation of plasticizers is possible

The muffle furnaces L 3/11 - LT 60/12 have been proven for daily laboratory use. These models stand out for their excellent workmanship, advanced and attractive design, and high level of reliability.

Standard Equipment
• Heating from two sides by ceramic heating plates (heating from three sides for muffle furnaces L 24/11 - LT 60/12) for an optimal temperature uniformity
• Temperature uniformity of +/− 5 K with closed fresh-air inlet in empty work space according to DIN 17052-1 at working temperatures above 800 °C
• Thermocouple type N (1100 °C)
• Ceramic heating plates with integral heating element which is safeguarded and easy to replace
• With lift door (LT)
• Dual shell ventilated housing made of textured stainless steel sheets for low surface temperature and high stability
• Exclusive use of insulation materials without categorization according to EC Regulation No 1272/2008 (CLP). This explicitly means that alumino silicate wool, also known as “refractory ceramic fiber” (RCF), which is classified and possibly carcinogenic, is not used.
• Adjustable air inlet integrated in door (see illustration)
• Exhaust air outlet in rear wall of furnace
• Controller with touch operation B510 (5 programs with each 4 segments)
• Solid state relays provide for lownoise operation

Option
• Chimney, chimney with fan or catalytic converter (not for L 1 and L 15)
• Over-temperature limiter with adjustable cutout temperature as temperature limiter to protect the furnace and load
• Protective gas connection to purge with non-flammable process gases (not available in combination with chimney, chimney with fan or catalytic converter) not gas tight
• Manual or automatic gas supply system
• Port for thermocouple in the rear wall or in the furnace door

Tray with fixed clamps F-1000 To load with 16 Erlenmeyer flasks with a volume of 1000 ml

For Single- and Multi-Channel use (not suitable with cassette small)
• Application: For standard applications
Features:
• Non-toxic, non-oxidizing
• Good resistance to acids, bases and inorganic media
• Very low gas permeability, good performance life
• Material: Thermoplastic soft PVC, transparent
• Complies with the standards: FDA (21 CFR 177.2601) and GLP
• Temperature range: -50 to +75 °C
• Sterilization: Can be autoclaved for 30 min at 1 bar and 120 °C (material may change color) or with ethylene oxide
• Restriction: Segregation of plasticizers is possible

The PC 3001 VARIO select pumping unit precisely controls the vacuum level in order to achieve unparalleled process control. This pump is suitable for even high boiling point solvents.

The integrated VACUU•SELECT controller provides an easy-to-use, application based interface that covers all common lab applications. The VACUU•SELECT controller has you covered. Use manual set-point-control for simple processes, run fully automated distillations, or create your own application with simple drag-and-drop editing. For solvent evaporation, the VACUU•SELECT controller detects solvent boiling and automatically adjusts the pump's motor speed to maintain process control.

The VARIO motor speed control also makes the pump whisper quiet and provides for exceptionally long maintenance intervals.

The inlet separator, made of glass with a robust protective coating, prevents particles and liquid droplets from entering the pump, preventing damage and extending pump life. And the exhaust vapor condenser allows for nearly complete recovery of solvents when used with a chilled water line or recirculating chiller for economical recycling and environmental protection.

Performance features
• simplify lab work with the VACUU•SELECT vacuum controller with graphic user interface and predefined applications
• automatic boiling point detection and continuous optimization of vacuum levels for quick process times
• compact and powerful; superior performance even with continuous condensate purge
• whisper quiet and ultra low vibration
• eco-friendly: extremely low power consumption and efficient solvent recover

For Single- and Multi-Channel use (not suitable with cassette small)
• Application: For standard applications
Features:
• Non-toxic, non-oxidizing
• Good resistance to acids, bases and inorganic media
• Very low gas permeability, good performance life
• Material: Thermoplastic soft PVC, transparent
• Complies with the standards: FDA (21 CFR 177.2601) and GLP
• Temperature range: -50 to +75 °C
• Sterilization: Can be autoclaved for 30 min at 1 bar and 120 °C (material may change color) or with ethylene oxide
• Restriction: Segregation of plasticizers is possible

The muffle furnaces L 3/11 - LT 60/12 have been proven for daily laboratory use. These models stand out for their excellent workmanship, advanced and attractive design, and high level of reliability.

Standard Equipment
• Heating from two sides by ceramic heating plates (heating from three sides for muffle furnaces L 24/11 - LT 60/12) for an optimal temperature uniformity
• Temperature uniformity of +/− 5 K with closed fresh-air inlet in empty work space according to DIN 17052-1 at working temperatures above 800 °C
• Thermocouple type N (1100 °C)
• Ceramic heating plates with integral heating element which is safeguarded and easy to replace
• With lift door (LT)
• Dual shell ventilated housing made of textured stainless steel sheets for low surface temperature and high stability
• Exclusive use of insulation materials without categorization according to EC Regulation No 1272/2008 (CLP). This explicitly means that alumino silicate wool, also known as “refractory ceramic fiber” (RCF), which is classified and possibly carcinogenic, is not used.
• Adjustable air inlet integrated in door (see illustration)
• Exhaust air outlet in rear wall of furnace
• Controller with touch operation C550
• Solid state relays provide for lownoise operation

Option
• Chimney, chimney with fan or catalytic converter (not for L 1 and L 15)
• Over-temperature limiter with adjustable cutout temperature as temperature limiter to protect the furnace and load
• Protective gas connection to purge with non-flammable process gases (not available in combination with chimney, chimney with fan or catalytic converter) not gas tight
• Manual or automatic gas supply system
• Port for thermocouple in the rear wall or in the furnace door

Tray with fixed clamps F-1500 To load 12 Erlenmeyer flasks with a volume of 1500 ml

For Single- and Multi-Channel use (not suitable with cassette small)
• Application: For standard applications
Features:
• Non-toxic, non-oxidizing
• Good resistance to acids, bases and inorganic media
• Very low gas permeability, good performance life
• Material: Thermoplastic soft PVC, transparent
• Complies with the standards: FDA (21 CFR 177.2601) and GLP
• Temperature range: -50 to +75 °C
• Sterilization: Can be autoclaved for 30 min at 1 bar and 120 °C (material may change color) or with ethylene oxide
• Restriction: Segregation of plasticizers is possible

The PC 3001 VARIO select pumping unit precisely controls the vacuum level in order to achieve unparalleled process control. This pump is suitable for even high boiling point solvents. The integrated VACUU•SELECT controller provides an easy-to-use, application based interface that covers all common lab applications. The VACUU•SELECT controller has you covered. Use manual set-point-control for simple processes, run fully automated distillations, or create your own application with simple drag-and-drop editing. For solvent evaporation, the VACUU•SELECT controller detects solvent boiling and automatically adjusts the pump's motor speed to maintain process control. The VARIO motor speed control also makes the pump whisper quiet and provides for exceptionally long maintenance intervals.
The inlet separator, made of glass with a robust protective coating, prevents particles and liquid droplets from entering the pump, preventing damage and extending pump life. The PC 3001 VARIO select TE is equiped with a dry ice condenser at the pump exhaust, so that no cooling water connection is required.

Performance features
• simplify lab work with the VACUU•SELECT vacuum controller with graphic user interface and predefined applications
• automatic boiling point detection and continuous optimization of vacuum levels for quick process times
• compact and powerful; superior performance even with continuous condensate purge
• whisper quiet and ultra low vibration
• eco-friendly: extremely low power consumption and efficient solvent recovery. Oil-free!

For Single- and Multi-Channel use (not suitable with cassette small)
• Application: Especially for hydrocarbons, mineral oil products and distillates
Features:
• Ideal for petrol, kerosene, heating oil, cutting solutions and coolants on a glycol base
• Resistant to ozone and UV
• Material: Thermoplastic soft PVC, translucent yellow
• Complies with the standards: GLP conform
• Temperature range: -40 to +75 °C
• Sterilization: Sterilization is not recommended
• Restriction: Not suitable for concentrated acids, lyes, food and pharmaceutics

The muffle furnaces L 3/11 - LT 60/12 have been proven for daily laboratory use. These models stand out for their excellent workmanship, advanced and attractive design, and high level of reliability.

Standard Equipment
• Heating from two sides by ceramic heating plates (heating from three sides for muffle furnaces L 24/11 - LT 60/12) for an optimal temperature uniformity
• Temperature uniformity of +/− 5 K with closed fresh-air inlet in empty work space according to DIN 17052-1 at working temperatures above 800 °C
• Thermocouple type S (1200 °C)
• Ceramic heating plates with integral heating element which is safeguarded and easy to replace
• With lift door (LT)
• Dual shell ventilated housing made of textured stainless steel sheets for low surface temperature and high stability
• Exclusive use of insulation materials without categorization according to EC Regulation No 1272/2008 (CLP). This explicitly means that alumino silicate wool, also known as “refractory ceramic fiber” (RCF), which is classified and possibly carcinogenic, is not used.
• Adjustable air inlet integrated in door (see illustration)
• Exhaust air outlet in rear wall of furnace
• Controller with touch operation B510 (5 programs with each 4 segments)
• Solid state relays provide for lownoise operation

Option
• Chimney, chimney with fan or catalytic converter (not for L 1 and L 15)
• Over-temperature limiter with adjustable cutout temperature as temperature limiter to protect the furnace and load
• Protective gas connection to purge with non-flammable process gases (not available in combination with chimney, chimney with fan or catalytic converter) not gas tight
• Manual or automatic gas supply system
• Port for thermocouple in the rear wall or in the furnace door

Tray with fixed clamps F-2000 To load 9 Erlenmeyer flasks with a volume of 2000 ml

For Single- and Multi-Channel use (not suitable with cassette small)
• Application: Especially for hydrocarbons, mineral oil products and distillates
Features:
• Ideal for petrol, kerosene, heating oil, cutting solutions and coolants on a glycol base
• Resistant to ozone and UV
• Material: Thermoplastic soft PVC, translucent yellow
• Complies with the standards: GLP conform
• Temperature range: -40 to +75 °C
• Sterilization: Sterilization is not recommended
• Restriction: Not suitable for concentrated acids, lyes, food and pharmaceutics

The PC 3001 VARIO select pumping unit precisely controls the vacuum level in order to achieve unparalleled process control. This pump is suitable for even high boiling point solvents. The integrated VACUU•SELECT controller provides an easy-to-use, application based interface that covers all common lab applications. The VACUU•SELECT controller has you covered. Use manual set-point-control for simple processes, run fully automated distillations, or create your own application with simple drag-and-drop editing. For solvent evaporation, the VACUU•SELECT controller detects solvent boiling and automatically adjusts the pump's motor speed to maintain process control. The VARIO motor speed control also makes the pump whisper quiet and provides for exceptionally long maintenance intervals.
The inlet separator, made of glass with a robust protective coating, prevents particles and liquid droplets from entering the pump, preventing damage and extending pump life. The included emission condenser Peltronic works without any cooling media like water or dry ice.

Performance features
• simplify lab work with the VACUU•SELECT vacuum controller with graphic user interface and predefined applications
• automatic boiling point detection and continuous optimization of vacuum levels for quick process times
• compact and powerful; superior performance even with continuous condensate purge
• whisper quiet and ultra low vibration
• eco-friendly: extremely low power consumption and efficient solvent recovery. Oil-free!

For Single- and Multi-Channel use (not suitable with cassette small)
• Application: Especially for hydrocarbons, mineral oil products and distillates
Features:
• Ideal for petrol, kerosene, heating oil, cutting solutions and coolants on a glycol base
• Resistant to ozone and UV
• Material: Thermoplastic soft PVC, translucent yellow
• Complies with the standards: GLP conform
• Temperature range: -40 to +75 °C
• Sterilization: Sterilization is not recommended
• Restriction: Not suitable for concentrated acids, lyes, food and pharmaceutics

The muffle furnaces L 3/11 - LT 60/12 have been proven for daily laboratory use. These models stand out for their excellent workmanship, advanced and attractive design, and high level of reliability.

Standard Equipment
• Heating from two sides by ceramic heating plates (heating from three sides for muffle furnaces L 24/11 - LT 60/12) for an optimal temperature uniformity
• Temperature uniformity of +/− 5 K with closed fresh-air inlet in empty work space according to DIN 17052-1 at working temperatures above 800 °C
• Thermocouple type S (1200 °C)
• Ceramic heating plates with integral heating element which is safeguarded and easy to replace
• With lift door (LT)
• Dual shell ventilated housing made of textured stainless steel sheets for low surface temperature and high stability
• Exclusive use of insulation materials without categorization according to EC Regulation No 1272/2008 (CLP). This explicitly means that alumino silicate wool, also known as “refractory ceramic fiber” (RCF), which is classified and possibly carcinogenic, is not used.
• Adjustable air inlet integrated in door (see illustration)
• Exhaust air outlet in rear wall of furnace
• Controller with touch operation C550
• Solid state relays provide for lownoise operation

Option
• Chimney, chimney with fan or catalytic converter (not for L 1 and L 15)
• Over-temperature limiter with adjustable cutout temperature as temperature limiter to protect the furnace and load
• Protective gas connection to purge with non-flammable process gases (not available in combination with chimney, chimney with fan or catalytic converter) not gas tight
• Manual or automatic gas supply system
• Port for thermocouple in the rear wall or in the furnace door

Tray with fixed clamps F-2500U to load 8 Ultra yield flasks with a volume of 2500 ml on a F-tray
