RO-ED ready pure water systems with ED cell, tank and pressure pump
The ready-to-connect pure water system from stakpure combines all treatment steps in one compact and low-noise unit. Pre-treatment, reverse osmosis, electro-deionisation for residual desalination, pure water tank and pressure boosting are integrated in a control cabinet to save space and are completely pre-assembled. Pure water units of the RO ED READY "to use" series produce pure water according to all common standards such as ASTM and DIN 285 + DIN EN 15883 and aqua purificata. Specially developed for the safe and economical supply of pure water to complete laboratory floors and AEMP's in medical practices and hospitals, as well as manufacturing plants in the food and pharmaceutical industries (aqua purificata for external parts cleaning), where space is still a scarce commodity. The clean water system is completed with a digital microprocessor control for display and control of all operating and performance parameters.

Design and scope of delivery
• Electronics control cabinet with transparent door to accommodate all system components
• Pre-treatment unit to protect against free chlorine and particles in the feed water
• Softening unit to protect against limescale and blockage
• Reverse osmosis unit for desalination and removal of removal of organic and inorganic impurities
• Electro-deionisation module for residual desalination Continuously self-regenerating - without chemicals
• Pure water tank incl. level control for automatic storage of the produced pure water
•Pressure boosting system incl. pressure control for low-noise low-noise delivery of the pure water to the end user
•Multilingual microprocessor control with LCD display for control and monitoring of RO systems. Display of Permeate conductivity, fully automatic flushing cycles and potential-free fault indication.

System structure softening plant
Volume-controlled system, for softening iron- and manganese-free drinking water, according to drinking water regulations, fully automatic, 5-step central control valve type FLECK 5600 SXT with microprocessor made of NORYL with integrated blending valve and water meter. Pressure tank made of corrosion-resistant GRP, incl. cation exchanger of highest quality, installed in cabinet tank with float valve
• Type: WEA 32 Compact
• Capacity: 32 m³x°dH
• Nominal flow rate: 0.32 m³/h
• Resin quantity: 8 litres
• Salt supply: 25kg
• Salt consumption: approx. 1.92 kg/reg.
• Water consumption: 0.08 m³/reg.
• Operating pressure: 2 to 6 bar
• Water temperature: max. 30°C
• Ambient temperature: max. 5 to 40°C
• Electrical connection: 220 V 50 Hz
• Dimensions of housing (WxDxH) 310 x 430 x 660 mm
• Connection: R1

System design Reverse Osmosis Unit
• Safety pressure switch for shutting off when feed water pressure is too low
• High-pressure pump for generating the working pressure
• Reverse osmosis membrane incl. pressure pipe and all necessary fittings
• Working pressure manometer for system monitoring and fault diagnosis
• 2 x solenoid valves for raw water and quality flushing
• 2 x regulating valves for setting the working pressure and the WCF rate
• Measuring cells for determining the raw and clean water conductivity values
• Complete piping made of PA, PP, POM and stainless steel materials

Structure electro-deionisation
• Electro-deionisation module
• Flow meter for pure water, concentrate and electrode rinse water
• Set of regulating valves
• Conductivity measuring cell
• Complete piping in PA, PP, POM and stainless steel
• Microprocessor control with LCD display for control and display of all operating and performance parameters.

Digital microprocessor control
Universally applicable for the automatic control and monitoring of reverse osmosis systems. The controller is equipped with one or optionally two conductivity meters with temperature compensation. Optional board for recorder outputs 4-20mA possible. Integrated in a separate electronic control cabinet for wall mounting. The following functions/operating modes are executed and displayed:
• Stand-by
• Production
• Rinse after production
• Flushing interval
• Maintenance
Adaptable options through programmable configuration that can be stored in a memory.

Properties
Menu-guided programming in the 2-line display
• Language selection for English, French, Spanish, Italian or Dutch
• Adaptation to user-specific requirements through programmable options
• Easy handling and control through the use of symbols on the control buttons
• Universally applicable even for larger reverse osmosis systems
• Production can be controlled via manual or level switch
• Maintenance interval display programmable via code
• Service number can be shown in the display
• Status display can be called up via info key for the following conditions: Current status for inputs and outputs, service telephone number, software version, programming status, type of fault messages, Interval rinsing with current time interval, manual rinsing with time specification, conductivity measuring probe, cell constants
• Display of the current permeate and pure water conductivity with indication of the desalination rate in a large green LED display.
• Connection of optional board for recorder outputs 4-20mA
• Inputs for : Production stop, storage tank full/empty, overpressure, raw water shortage, motor protection switch, alarm reset, temperature sensor (optional), concentrate monitor
• Integrated conductivity meter with measuring range switchover
• Cell constants adjustable from for measurement of conductivities 0.1- 100000μS/cm
• Cell constants programmable from 0.01-10.00cm
• Manual and automatic temperature compensation
• Extension of conductivity measurement by dual function display
• Thermoswitch for pressure pump with fault signal available as option
• Outputs for : Pressure pump (contactor), input solenoid valve, flush valve, permeate valve, fault signal contact
• Insensitive to mains failures, as all programme functions are stored without battery.
• Large microprocessor memory capacity with "watchdog" against illegal "Operation Code and frequency monitoring
• Manufacture of the control unit in compliance with the EMC standard by means of galvanic isolation between microprocessor and input and output circuits, plus extra built-in filter
• Available input/output voltages (input/output) 24/24V 115/115V 230/230V

System design pure water tank
Storage tanks made of black PE for storing pure water from reverse osmosis systems. Closed and opaque design, angular, incl. 200 mm manhole for cleaning. The tank is completely piped and available with optional additional equipment. Incl. level control with min./max. control for fully automatic storage.
Scope of delivery:
• CO2 absorber, tank ventilation and sterile overflow
o Nominal volume: approx. 200 litres
o Material: PE black
o Inlet and overflow connection: R ¾".
o Connection outlet: R 1 ¼"

System design Pressure boosting
The PST 2500 PC pump station is a self-priming, horizontal, single-stage centrifugal pump with built-in ejector. The squirrel-cage motor and the use of a mechanical shaft seal make the unit maintenance-free and insensitive to faults. Long service life due to the use of stainless steel for all highly stressed parts, such as impeller and housing. In combination with the automatic pressure control, the unit becomes a complete supply station.
Single stage centrifugal pump
Automatic pressure control
• Type: PST 2500 PC
• Pumping medium: water
• Actual flow rate 3.4 m³/h
• At actual delivery head: 22 m
• Switch-on pressure Pressure control: 2.2 bar
• Material impeller and casing: stainless steel AISI 304
• Ambient temperature: max. 40°C
• Electrical connection: 230 V / 50 Hz
• Power consumption 850 W
• Dimensions incl. pressure control approx. W 206 x D 364 x H 500 mm
• Connection inlet d25 grommet
• Connection outlet R ¾"
• Order no. 16551200

Technical data
for connection to softened or hardness-stabilised drinking water in accordance with the German Drinking Water Ordinance.
• Blocking index: max. 3
• Salt content: max. 2,000 mg/l
• Chlorine concentration: < 0.01 mg/l
• Manganese content: < 0.05 mg/l
• Iron content: < 0.05 mg/l
• CO2 content: max. 15 mg/l
• SiO2 content: max. 0.4 mg/l
• pH range: 4 to 11

Pure water values
• RO capacity ( at 10°C ): 100 l/h
• RO membrane retention rate: > 99 % salts, germs and bacteria
• WCF rate adjustable up to 75
• Output EDI ( at 10°C ): 50-80 l/h
• Membrane retention rate RO: > 99 % salts, germs and bacteria
• Residual conductivity ED: 0.06 to 1 μS/cm*
• Type. Residual conductivity ED: 0.1 μS/cm*
• TOC value ED: < 30 ppb
• Silicate and germ reduction ED: > 99 %*
• WCF rate RO/ED adjustable: up to 75/90

Connection values
• Ambient temperature: 5 - 40°C
• Water temperature: 5 - 35°C
• Raw water pressure RO: 2 to 6 bar
• Working pressure RO: max. 14 bar
• Working pressure ED: 1 to 4 bar
• Clean water back pressure: max. 0 to 1 bar
• Supply voltage: 230 volts / 50 Hz
• Connected load: 1.5 kW
• Connection inlet:DN 20
• Connection outlet: DN 20
• Brine connection: DN 10
• Dimensions (WxDxH): 1020 x 600 x 1850 mm
• Weight approx.: 270 kg
• Order no. 17600080

The compact for H2O pure type ASTM II + DIN 285
RO ED ready mini is the system of choice when pure water is needed for the complete laboratory supply and space is limited. The system meets international water standards such as ASTM, ISO 3696, CLSI, DIN 285 and is economically maximised by the combination with the continuously self-regenerating electro-deionisation. In addition, the system holds 50 litres of pure water in a 50l storage tank with optional recirculation module for withdrawal. A frequency-controlled pressure and ring line pump can be used to supply downstream end devices and/or ring line systems. Mobile on castors, the system can be
integrated in a 90 cm laboratory base cabinet to save space. The RO ED ready mini system is predestined for the supply of autoclaves or dishwashers and ultrapure water systems in laboratory and medical technology.
Features
• All-in-one unit - completely pre-rolled and ready for connection
• Space-saving integration in a 90' base cabinet
• Economical ultrapure water quality ASTM II + DIN 285
• Continuous residual desalination by means of electro-deionisation
• 50 l pure water tank with optional recirculation module
• Clear control with graphic display
• Leakage sensor as standard
• Frequency-controlled pressure and ring line pump

System design - as standard
• Mobile T-frame on castors to accommodate all system components made of PE. With drip tray over the entire surface - accumulation edge 4 cm.
• Pre-treatment unit - pore size 5 μm with activated carbon to protect the membranes from particles and chlorine
• Wide range power supply with automatic voltage adjustment to 48 V enables international use with only one power supply
• Low-noise LongLife RO pressure pump (< 40dB) with automatic rinsing cycle to flush deposits from the membranes.
• HighPerformance reverse osmosis modules for the retention of inorganic and organic ingredients - extremely powerful
• Electro-deionisation module for continuous and economical resin regeneration without the addition of chemicals
• Pure water tank with a volume of 50 l made of black PE and conical bottom drain for complete emptying of residues
• CO2 absorber, sterile tank ventilation filter and sterile tank overflow protect against contamination by airborne germs and carbon dioxide
• Quality flushing valve for complete disinfection of all parts in contact with the media as well as quality flushing in interval mode
• Multilingual menu navigation for controlling and monitoring all operating and performance parameters as graphic display
• Frequency-controlled pressure and ring line pump with pressure sensor, switch box, 2 l pressure compensation vessel for supplying downstream terminal devices - 1 m³h/ at 4 bar

Optionally available:
• Recirculation module for complete tank recirculation and connection of external ring line systems - consisting of solenoid valve, timer and pressure maintenance
• UV disinfection unit as immersion tube system for the clean water tank Output 16 W, wavelength 254 nm, with ballast unit

Microprocessor control
• Multilingual microprocessor control with graphic display and colour change green/red on error message
• Individual setting options for conductivity display in MΩxcm or μS/cm as well as language switchover German/English
• Multi-stage conductivity & temperature monitoring for permeate & pure water, temperature-compensated with infinitely variable limit value setting
• USP-compliant and highly precise thanks to automatic adjustment before each measurement with integrated reference resistor and temperature compensation that can be switched off
• Continuous monitoring of the UV unit and leakage monitoring with error display and automatic safety shutdown of the water supply

Feed water requirements
softened drinking water according to DIN 2000
• Feed water temperature: +2°C to 35
• Feed water pressure: 2 to 6 bar
• Manganese and iron content: < 0.05 mg/l
• Chlorine content: < 0.1 mg/l
• Blocking index (SDI): max. 3

Pure water values type II
• Pure water conductivity*: 10-1 MΩxcm - 0.1 - 1 μS/cm
• Silicate retention* : > 99
• Pure water output at 15°C: 20 l/h
• Typical applications: Laboratory water supply type II / DIN 285; Supply of autoclaves and laboratory dishwashers
*in dependence of feed water quality and CO2

Technical data
• Ambient temperature: +2 to 35°C
• Supply voltage: 230 Volt / 50-60 Hz
• Total connected load: 1.1 kW
• Connection size: R ¾"
• Dimensions (WxDxH): 800 x 600 x 800 mm

Flat bath cover for PURA 10 with 4 openings, 92 mm diameter with appropriate set of rings.

High-performance ultrasonic cleaner for versatile applications

The proven and particularly robust SONOREX ultrasonic baths clean thoroughly and gently by means of intensive cavitation bubbles, even in the hard-to-reach places of the cleaning objects.

A user-friendly rotary handle control is used for easy adjustment of the cleaning time. Matching baskets, lids and cleaning and disinfection concentrates are available as accessories for optimally coordinated ultrasonic cleaning.

The SONOREX TECHNIK range currently consists of 4 series with common characteristics:

• welded stainless steel cleaning tank, 2 mm
• overflow gutter: combined with an oil separator and or a filtering system to continuously remove dirt, oils and grease floating on the surface of the tank
• cleaning fluid filling level mark, facilitates dosing
• welded drain with three-way ball valve for emptying or filling the tank and connecting a filtration system
• additional drain for connecting an oil separator and draining the overflow gutter
• heating: all models are available with (UH) or without (U) heating: on / off with control indicator, thermostatic, adjustable from 30 to 80 ° C
• case protected against drops of water in stainless steel
• for baskets, possibility of having a motorized lift with agitation function
• possibility of making sets of 2 to 5 stations with ultrasonic bath, rinsing bath, drying tank with a motorized translator / elevator / agitator
• inclined tank bottom for better cleaning results by optimal sound propagation. This facilitates the emptying of the tank and makes it possible to avoid as much as possible the accumulation of dirt and residual liquids at the bottom of the tank
• ultrasound: on / off with control indicator, timer 1 to 15 min. or continuous operation
• 40 kHz frequency generator (built-in)

With their convincing price/performance ratio and the fast heat-up rates, these compact muffle furnaces are perfect for many applications in the laboratory. Quality features like the dual shell furnace housing of rust-free stainless steel, their compact, lightweight constructions, or the heating elements encased in quartz glass tubes make these models reliable partners for your application.

Standard Equipment
• Heating from two sides from heating elements protected in quartz glass tubes
• Fast heating times
• Maintenance-friendly replacement of heating elements and insulation
• Housing coated in RAL 9003
• Solid state relays provide for lownoise operation
• Dual shell housing made of textured stainless steel sheets with additional fan cooling for low surface temperature
• Exclusive use of insulation materials without categorization according to EC Regulation No. 1272/2008 (CLP)
• Flap door which can also be used as a work platform
• Exhaust air outlet in rear wall
• Compact dimensions and light weight
• Controller mounted under the door to save space
• Controller R7 (adjustable for one temperature)

Temperature-sensitive medicines, vaccines and samples must be stored in the most reliable conditions. To be available whenever they are needed, they must be stored round the clock in maximum safety.
Liebherr pharmaceutical refrigerators compliant with DIN 13277 have been specially designed for these particular requirements. With their dynamic cooling system, highly effective insulation and precise temperature control, they guarantee absolutely reliable storage of sensitive substances and preparations. Visual and audible alarm systems provide additional safety.
The combination of maximum temperature stability, energy efficiency, robustness and ease of use lightens your daily workload – and saves you money in the long term because of the extremely low energy and operating costs.

Product features

• Pharmacy drawers
Optimal overview, easy access, high temperature stability: the practical organisational system made of cold-conducting aluminium comes with a transparent front, perforated base, flexible dividing walls and a ¾-extension drawer. Medicines, vaccines and other items can be quickly found – and the door closed again with minimal loss of cold air.

• Integrated data logger
The integrated logger records the temperature profile, alarm history and service information for up to five years. The data can be read out directly from the appliance via the USB interface.

• +2 °C SafetyDevice
If the temperature falls below +2 °C due to a malfunction, the SafetyDevice takes control, stabilising the temperature, activating the alarm and protecting the contents from freezing.

• Power failure alarm
If a malfunction occurs, an integrated battery provides a visual and audible alarm and takes over the power supply. As soon as the power is restored, the time of failure and the maximum temperature reached are displayed.

• Vertical LED lighting
Vertical LED lighting provides optimal illumination of the interior over the entire height of the appliance. This not only saves you time looking for things, but, above all, cuts energy costs.

• LightAlarm
In the event of an uncontrolled temperature rise or other problems, the interior light of the appliance starts flashing. This quickly shows when action is needed.

• Easy-to-clean interior
The inner liner made of fully recyclable, robust and odourless polystyrene is manufactured in one piece without joints. This makes it quick and easy to clean the large, rounded corners

• Feedthrough for external sensors
An integrated opening allows a separate sensor to be connected for additional temperature monitoring without having to drill holes or break the door seal.

• SmartLock
To prevent products from accidentally entering circulation after an interruption in the cold chain, SmartLock automatically locks the door if there is an alarm. Only authorised persons can unlock it again.

• SmartMonitoring
The cloud-based digital solution continuously monitors and documents temperatures and alerts you immediately via email, text message or phone if any deviations occur.

• Integrated WiFi/LAN interface
The integrated WiFi/LAN interface enables you to easily connect your appliances with Liebherr SmartMonitoring or existing local systems.

• Min./max. temperature log
The min./max. temperature log stores the minimum and maximum interior temperatures and shows on the display whether the storage temperatures were within the tolerance limits

• Antimicrobial handle with opening mechanism
The smooth-turning handle contains special antimicrobial substances that make it particularly hygienic. Regular and time-consuming disinfection is not necessary.

• Replaceable door seal
Save time and money: the insertable Liebherr door seals are easy to change. If a seal is damaged, you can replace it yourself without any tools. Contact Liebherr Customer Service to purchase replacements.

• Self-closing door < 90°
To make loading, unloading and cleaning easier, the appliance door stays open if opened by more than 90°. If the opening angle is less than 90°, it closes automatically for safety

Temperature-sensitive medicines, vaccines and samples must be stored in the most reliable conditions. To be available whenever they are needed, they must be stored round the clock in maximum safety.
Liebherr pharmaceutical refrigerators compliant with DIN 13277 have been specially designed for these particular requirements. With their dynamic cooling system, highly effective insulation and precise temperature control, they guarantee absolutely reliable storage of sensitive substances and preparations. Visual and audible alarm systems provide additional safety.
The combination of maximum temperature stability, energy efficiency, robustness and ease of use lightens your daily workload – and saves you money in the long term because of the extremely low energy and operating costs.

Product features

• Integrated data logger
The integrated logger records the temperature profile, alarm history and service information for up to five years. The data can be read out directly from the appliance via the USB interface.

• +2 °C SafetyDevice
If the temperature falls below +2 °C due to a malfunction, the SafetyDevice takes control, stabilising the temperature, activating the alarm and protecting the contents from freezing.

• Power failure alarm
If a malfunction occurs, an integrated battery provides a visual and audible alarm and takes over the power supply. As soon as the power is restored, the time of failure and the maximum temperature reached are displayed.

• Vertical LED lighting
Vertical LED lighting provides optimal illumination of the interior over the entire height of the appliance. This not only saves you time looking for things, but, above all, cuts energy costs.

• LightAlarm
In the event of an uncontrolled temperature rise or other problems, the interior light of the appliance starts flashing. This quickly shows when action is needed.

• Easy-to-clean interior
The inner liner made of fully recyclable, robust and odourless polystyrene is manufactured in one piece without joints. This makes it quick and easy to clean the large, rounded corners

• Feedthrough for external sensors
An integrated opening allows a separate sensor to be connected for additional temperature monitoring without having to drill holes or break the door seal.

• SmartLock
To prevent products from accidentally entering circulation after an interruption in the cold chain, SmartLock automatically locks the door if there is an alarm. Only authorised persons can unlock it again.

• SmartMonitoring
The cloud-based digital solution continuously monitors and documents temperatures and alerts you immediately via email, text message or phone if any deviations occur.

• Integrated WiFi/LAN interface
The integrated WiFi/LAN interface enables you to easily connect your appliances with Liebherr SmartMonitoring or existing local systems.

• Min./max. temperature log
The min./max. temperature log stores the minimum and maximum interior temperatures and shows on the display whether the storage temperatures were within the tolerance limits

• Antimicrobial handle with opening mechanism
The smooth-turning handle contains special antimicrobial substances that make it particularly hygienic. Regular and time-consuming disinfection is not necessary.

• Replaceable door seal
Save time and money: the insertable Liebherr door seals are easy to change. If a seal is damaged, you can replace it yourself without any tools. Contact Liebherr Customer Service to purchase replacements.

• Self-closing door < 90°
To make loading, unloading and cleaning easier, the appliance door stays open if opened by more than 90°. If the opening angle is less than 90°, it closes automatically for safety

Liebherr refrigerator for laboratories and research

Constant temperatures are essential when storing sensitive substances. This especially applies to work in laboratories, where even the slightest deviations can jeopardise the quality of research results. This is why Liebherr has developed new refrigerators and freezers specifically for this sector, combining maximum refrigeration performance with optimum temperature stability. Innovative safety features with monitoring and alarm functions offer all-round protection from all kinds of incident and malfunction. The next generation of appliances also set new standards in terms of energy efficiency and total cost of ownership. On the next few pages we present the latest results of research and development by the refrigeration specialists at Liebherr and show how they can benefit safety in your laboratory.

Product features

• Integrated data logger
The integrated logger records the temperature profile, alarm history and service information for up to five years. The data can be read out directly from the appliance via the USB interface.

• Min./max. temperature log
The min./max. temperature log stores the minimum and maximum interior temperatures and shows on the display whether the storage temperatures were within the tolerance limits.

• +2 °C SafetyDevice
If the temperature falls below +2 °C due to a malfunction, the SafetyDevice takes control, stabilising the temperature, activating the alarm and protecting the contents from freezing

• Power failure alarm
If a malfunction occurs, an integrated battery provides a visual and audible alarm and takes over the power supply. As soon as the power is restored, the time of failure and the maximum temperature reached are displayed.

• LightAlarm
In the event of an uncontrolled temperature rise or other problems, the interior light of the appliance starts flashing. This visually shows when action is needed.

• Feedthrough for external sensors
An integrated opening allows a separate sensor to be connected for additional temperature monitoring without having to drill holes or break the door seal.

• Mechanical lock
Liebherr professional appliances are equipped with a mechanical lock and two keys. This ensures that unauthorised persons cannot access your valuable and sensitive stored goods.

• SmartMonitoring
The cloud-based digital solution continuously monitors and documents temperatures and alerts you immediately via email, text message or phone if any deviations occur.

• Integrated WiFi/LAN interface
The integrated WiFi/LAN interface enables you to easily connect your appliances with Liebherr SmartMonitoring or existing local systems.

• Easy-to-clean interior
The inner liner made of fully recyclable, robust and odourless polystyrene is manufactured in one piece without joints. This makes it quick and easy to clean the large, rounded corners.

• Replaceable door seal
Save time and money: the insertable Liebherr door seals are easy to change. If a seal is damaged, you can replace it yourself without any tools. Contact Liebherr Customer Service to purchase replacements.

• Self-closing door < 90°
To make loading, unloading and cleaning easier, the appliance door stays open if opened by more than 90°. If the opening angle is less than 90°, it closes automatically for safety

• ±3 K temperature stability
Temperature fluctuations must be minimal to ensure that the quality of sensitive substances is preserved. Liebherr Laboratory refrigerators have an impressive maximum deviation of just ±3 from the set temperature. This not only maintains the storage climate, but also the value of your stored goods.

• Standard compliance
The devices fully comply with the DIN 13277 standard and the IEC 61010-2-011 standard.

Liebherr refrigerator for laboratories and research

Constant temperatures are essential when storing sensitive substances. This especially applies to work in laboratories, where even the slightest deviations can jeopardise the quality of research results. This is why Liebherr has developed new refrigerators and freezers specifically for this sector, combining maximum refrigeration performance with optimum temperature stability. Innovative safety features with monitoring and alarm functions offer all-round protection from all kinds of incident and malfunction. The next generation of appliances also set new standards in terms of energy efficiency and total cost of ownership. On the next few pages we present the latest results of research and development by the refrigeration specialists at Liebherr and show how they can benefit safety in your laboratory.

Product features

• Min./max. temperature log
The min./max. temperature log stores the minimum and maximum interior temperatures and shows on the display whether the storage temperatures were within the tolerance limits.

• +2 °C SafetyDevice
If the temperature falls below +2 °C due to a malfunction, the SafetyDevice takes control, stabilising the temperature, activating the alarm and protecting the contents from freezing

• Power failure alarm
When mains power return the device gives a visual and audible warning signal.

• LightAlarm
In the event of an uncontrolled temperature rise or other problems, the interior light of the appliance starts flashing. This visually shows when action is needed.

• Feedthrough for external sensors
An integrated opening allows a separate sensor to be connected for additional temperature monitoring without having to drill holes or break the door seal.
• Mechanical lock
Liebherr professional appliances are equipped with a mechanical lock and two keys. This ensures that unauthorised persons cannot access your valuable and sensitive stored goods.

• SmartMonitoring (optional)
The cloud-based digital solution continuously monitors and documents temperatures and alerts you immediately via email, text message or phone if any deviations occur.

• WiFi/LAN interface (optional)
The WiFi/LAN interface enables you to easily connect your appliances with Liebherr SmartMonitoring or existing local systems.

• Easy-to-clean interior
The inner liner made of fully recyclable, robust and odourless polystyrene is manufactured in one piece without joints. This makes it quick and easy to clean the large, rounded corners.

• Replaceable door seal
Save time and money: the insertable Liebherr door seals are easy to change. If a seal is damaged, you can replace it yourself without any tools. Contact Liebherr Customer Service to purchase replacements.

• Self-closing door < 90°
To make loading, unloading and cleaning easier, the appliance door stays open if opened by more than 90°. If the opening angle is less than 90°, it closes automatically for safety

• ±3 °C temperature stability
Temperature fluctuations must be minimal to ensure that the quality of sensitive substances is preserved. Liebherr Laboratory refrigerators have an impressive maximum deviation of just ±3 °C from the set temperature. This not only maintains the storage climate, but also the value of your stored goods.

• Standard compliance
The devices fully comply with the DIN 13277 standard and the IEC 61010-2-011 standard.

Liebherr offers refrigerators and freezers with a spark-free interior specifically for storing explosive and highly flammable substances in laboratories and in the chemical industry. The inner liners meet the safety requirements of EU Directive 2014/34/EU (ATEX) and have been tested according to the EN 1127-1, IEC 60079-0 and IEC 60079-15 standards by electro-suisse – SEV (Swiss association for electrical and power engineering and information technology), an approved ATEX conformity evaluation organisation.

Product features

• +2 °C SafetyDevice
If the temperature falls below +2 °C due to a malfunction, the SafetyDevice takes control, stabilising the temperature, activating the alarm and protecting the contents from freezing

• ±3 °C temperature stability
Temperature fluctuations must be minimal to ensure that the quality of sensitive substances is preserved. Liebherr Laboratory refrigerators have an impressive maximum deviation of just ±3 °C from the set temperature. This not only maintains the storage climate, but also the value of your stored goods.

• Power failure info
The power failure info function reports when the appliance was temporarily without power and what the maximum temperature was during this time. This allows you to better assess the potential loss of quality.

• Min./max. temperature log
The min./max. temperature log stores the minimum and maximum interior temperatures and shows on the display whether the storage temperatures were within the tolerance limits.

• Easy-to-clean interior
The inner liner made of fully recyclable, robust and odourless polystyrene is manufactured in one piece without joints. This makes it quick and easy to clean the large, rounded corners.

• Feedthrough for external sensors
An integrated opening allows a separate sensor to be connected for additional temperature monitoring without having to drill holes or break the door seal.

• Mechanical lock
Liebherr professional appliances are equipped with a mechanical lock and two keys. This ensures that unauthorized persons cannot access your valuable and sensitive stored goods.

• SmartMonitoring
The cloud-based digital solution continuously monitors and documents temperatures and alerts you immediately via email, text message or phone if any deviations occur

• Retrofittable WiFi/LAN interface
The retrofittable WiFi/LAN interface enables you to easily connect your appliances with Liebherr SmartMonitoring or existing local systems.

• Antimicrobial handle with opening mechanism
The smooth-turning handle contains special antimicrobial substances that make it particularly hygienic. Regular and time-consuming disinfection is not necessary

• Replaceable door seal
Save time and money: the insertable Liebherr door seals are easy to change. If a seal is damaged, you can replace it yourself without any tools. Contact Liebherr Customer Service to purchase replacements.

•Self-closing door < 90°
To make loading, unloading and cleaning easier, the appliance door stays open if opened by more than 90°. If the opening angle is less than 90°, it closes automatically for safety.

Liebherr freezers for laboratory and research use meet the highest requirements, especially in terms of safety and temperature stability.

• Integrated data logger
The integrated logger records the temperature profile, alarm history and service information for up to five years. The data can be read out directly from the appliance via the USB interface.

• Min./max. temperature log
The min./max. temperature log stores the minimum and maximum interior temperatures and shows on the display whether the storage temperatures were within the tolerance limits.

• +2 °C SafetyDevice
If the temperature falls below +2 °C due to a malfunction, the SafetyDevice takes control, stabilising the temperature, activating the alarm and protecting the contents from freezing

• Power failure alarm
If a malfunction occurs, an integrated battery provides a visual and audible alarm and takes over the power supply. As soon as the power is restored, the time of failure and the maximum temperature reached are displayed.

• LightAlarm
In the event of an uncontrolled temperature rise or other problems, the interior light of the appliance starts flashing. This visually shows when action is needed.

• Feedthrough for external sensors
An integrated opening allows a separate sensor to be connected for additional temperature monitoring without having to drill holes or break the door seal.

• Mechanical lock
Liebherr professional appliances are equipped with a mechanical lock and two keys. This ensures that unauthorised persons cannot access your valuable and sensitive stored goods.

• SmartMonitoring
The cloud-based digital solution continuously monitors and documents temperatures and alerts you immediately via email, text message or phone if any deviations occur.

• Integrated WiFi/LAN interface
The integrated WiFi/LAN interface enables you to easily connect your appliances with Liebherr SmartMonitoring or existing local systems.

• Easy-to-clean interior
The inner liner made of fully recyclable, robust and odourless polystyrene is manufactured in one piece without joints. This makes it quick and easy to clean the large, rounded corners.

• Replaceable door seal
Save time and money: the insertable Liebherr door seals are easy to change. If a seal is damaged, you can replace it yourself without any tools. Contact Liebherr Customer Service to purchase replacements.

• Self-closing door < 90°
To make loading, unloading and cleaning easier, the appliance door stays open if opened by more than 90°. If the opening angle is less than 90°, it closes automatically for safety

• NoFrost technology
Liebherr professional laboratory appliances no longer need manual defrosting. Any moisture that occurs is bound by the fan-assisted cooling, and when necessary, defrosting phases remove any remaining moisture particles from of the interior – for convenient, safe, and ice-free storage.

• ±5 °C temperature stability
Sensitive substances cannot be subjected to large deviations from the set storage temperature. Liebherr freezers guarantee a temperature fluctuation of no more than ±5 °C, so that the valuable goods you store in them are optimally protected and their quality is preserved.

• Standard compliance
The devices fully comply with the DIN 13277 standard and the IEC 61010-2-011 standard.

Liebherr freezers for laboratory and research use also meet the highest requirements, especially in terms of safety and temperature stability.

• Min./max. temperature log
The min./max. temperature log stores the minimum and maximum interior temperatures and shows on the display whether the storage temperatures were within the tolerance limits.

• +2 °C SafetyDevice
If the temperature falls below +2 °C due to a malfunction, the SafetyDevice takes control, stabilising the temperature, activating the alarm and protecting the contents from freezing

• Power failure alarm
Network failure alarm after a power failure.

• Feedthrough for external sensors
An integrated opening allows a separate sensor to be connected for additional temperature monitoring without having to drill holes or break the door seal.

• Mechanical lock
Liebherr professional appliances are equipped with a mechanical lock and two keys. This ensures that unauthorised persons cannot access your valuable and sensitive stored goods.

• SmartMonitoring (optional)
The cloud-based digital solution continuously monitors and documents temperatures and alerts you immediately via email, text message or phone if any deviations occur.

• WiFi/LAN interface (optional)
The integrated WiFi/LAN interface enables you to easily connect your appliances with Liebherr SmartMonitoring or existing local systems.

• Easy-to-clean interior
The inner liner made of fully recyclable, robust and odourless polystyrene is manufactured in one piece without joints. This makes it quick and easy to clean the large, rounded corners.

• Replaceable door seal
Save time and money: the insertable Liebherr door seals are easy to change. If a seal is damaged, you can replace it yourself without any tools. Contact Liebherr Customer Service to purchase replacements.

• Self-closing door < 90°
To make loading, unloading and cleaning easier, the appliance door stays open if opened by more than 90°. If the opening angle is less than 90°, it closes automatically for safety

• SmartFrost technology
Thanks to the SmartFrost technology, the frosting of the interior and stored products is significantly reduced. Defrosting is required less often – and if it is, it is made much easier by the smooth, easy-to-clean inner walls. The evaporator foamed into the insulation ensures high energy efficiency and uniform cooling.

• ±5 °C temperature stability
Sensitive substances cannot be subjected to large deviations from the set storage temperature. Liebherr freezers guarantee a temperature fluctuation of no more than ±5 °C, so that the valuable goods you store in them are optimally protected and their quality is preserved.

• Standard compliance
The devices fully comply with the DIN 13277 standard and the IEC 61010-2-011 standard.

Liebherr offers refrigerators and freezers with a spark-free interior specifically for storing explosive and highly flammable substances in laboratories and in the chemical industry. The inner liners meet the safety requirements of EU Directive 2014/34/EU (ATEX) and have been tested according to the EN 1127-1, IEC 60079-0 and IEC 60079-15 standards by electro-suisse – SEV (Swiss association for electrical and power engineering and information technology), an approved ATEX conformity evaluation organisation.

Product features

• +2 °C SafetyDevice
If the temperature falls below +2 °C due to a malfunction, the SafetyDevice takes control, stabilising the temperature, activating the alarm and protecting the contents from freezing

• ±5 °C temperature stability
Sensitive substances cannot be subjected to large deviations from the set storage temperature. Liebherr freezers guarantee a temperature fluctuation of no more than ±5 °C, so that the valuable goods you store in them are optimally protected and their quality is preserved.

• Power failure info
Mains failure alarm after a power failure.

• Min./max. temperature log
The min./max. temperature log stores the minimum and maximum interior temperatures and shows on the display whether the storage temperatures were within the tolerance limits.

• Easy-to-clean interior
The inner liner made of fully recyclable, robust and odourless polystyrene is manufactured in one piece without joints. This makes it quick and easy to clean the large, rounded corners.

• Feedthrough for external sensors
An integrated opening allows a separate sensor to be connected for additional temperature monitoring without having to drill holes or break the door seal.

• Mechanical lock
Liebherr professional appliances are equipped with a mechanical lock and two keys. This ensures that unauthorized persons cannot access your valuable and sensitive stored goods.

• SmartMonitoring (optional)
The cloud-based digital solution continuously monitors and documents temperatures and alerts you immediately via email, text message or phone if any deviations occur

• Retrofittable WiFi/LAN interface
The retrofittable WiFi/LAN interface enables you to easily connect your appliances with Liebherr SmartMonitoring or existing local systems.

• Antimicrobial handle with opening mechanism
The smooth-turning handle contains special antimicrobial substances that make it particularly hygienic. Regular and time-consuming disinfection is not necessary
•
Replaceable door seal
Save time and money: the insertable Liebherr door seals are easy to change. If a seal is damaged, you can replace it yourself without any tools. Contact Liebherr Customer Service to purchase replacements.

•Self-closing door < 90°
To make loading, unloading and cleaning easier, the appliance door stays open if opened by more than 90°. If the opening angle is less than 90°, it closes automatically for safety.

• SmartFrost
Where there’s no ice, there’s no need to defrost: SmartFrost greatly reduces the frost build-up in the interior and on stored products. Defrosting is required less often – and when it is necessary, it is made much easier by the smooth, easy-to-clean interior walls. The evaporator is embedded in foam insulation, ensuring high energy efficiency and uniform cooling.

Accurate dosing is particularly important in the pharmaceutical, cosmetic or food sector.
Comprehensible process conditions are a prerequisite for the safe conveyance of sensitive media. This is ensured by a control accuracy of ±0.5% and precise speed adjustment (5 — 120 rpm). In addition, an optional foot switch allows the pump to be operated in closed exhaust hoods. The parameters - speed, direction of rotation and on/off function - can be controlled externally either through the analog or digital interface. In this model, you can choose between a single-channel or multichannel pump head. Flow rates vary depending on the pump head: the single-channel head has a flow rate of 0.38 — 813 ml/min; for the multi-channel head 0.005 — 364 ml/min. Depending on the focus of the process, the following parameters can be set on the device: Speed, tubing diameter, flow rate display, metering volume, interval dosing and break times. The pump can be calibrated for optimum dosing results.
Other technical Data:
• Speed setting: digital
• Electronic speed control: digital
• Select direction of rotation: CW / CCW
• Analog interface: for speed 0 - 10 V / 4 - 20 mA direction of rotation start/stop
• Safety feature: electronic current limiter and overheat protection

This peristaltic pump is ideal for the simple conveying of all media. The pump drive of this model makes it possible to switch between a single channel and multi-channel pump head. By simply flipping the switch, it can also be conveyed in an anti-clockwise direction. Depending on the adapted pump head, a flow rate of 0.83 - 861 ml/min for the single-channel and 0.005 - 364 ml/min for the multi-channel pump head is guaranteed. The Core 120 conveys with a control accuracy of ± 2% at a speed range of 10 - 120 rpm.
• Speed setting: scale
• Electronic speed control: digital
• Select direction of rotation: CW / CCW
• Safety feature: overheat protection

This model has a flow rate of 2.0 — 4,056 ml/min and is designed for operation with singlechannel pump heads. The analog interface makes it possible that all functions can be controlled externally. A control accuracy of ±0.5% and a conveyor speed of 24 to 600 rpm provide optimum process conditions. In addition, sensitive media can be protected from influence by using the optional foot switch. Like all Heidolph peristaltic pumps, the conveying direction of this model can be changed by a simple push of a button. Furthermore, the accelerated filling and emptying of the tubing is simplified, since here only the button for the maximum speed has to be pressed.
Other technical Data:
• Speed setting: scale
• Electronic speed control: digital
• Select direction of rotation: CW / CCW
• Analog interface: for speed 0 - 10 V / 4 - 20 mA direction of rotation start/stop
• Safety feature: electronic current limiter and overheat protection

For reproducible results and liquid transfer
The pump drive of the model 120 of the Hei-FLOW Expert series can be operated with either single-channel or multi-channel pump heads. The flow rates with single-channel pump heads are in the range of 0.38 — 813 ml/min; with multi-channel pump eads from 0.005 — 329 ml/min. By integrating an analog interface, it is possible to control all functions externally. In addition, an optional foot switch can be adapted to enable dosing by foot pressure. Hands thus remain free to perform other work, for example, to hold the tubing and the vessel. A speed of 5 — 120 rpm with a control accuracy of ±0.5% guarantees optimum process results.
Other technical Data:
• Speed setting: scale
• Electronic speed control: digital
• Select direction of rotation: CW / CCW
• Analog interface: for speed 0 - 10 V / 4 - 20 mA direction of rotation start/stop
• Safety feature: electronic current limiter and overheat protection

• The ability to switch between precise dosing and fast conveying make this pump model the perfect complement to a reactor system. With a flow rate of 2.0 - 4,056 ml / min, when operated with single-channel pump heads, flows from feed-batch and chemostat modes of operation can be conveyed precisely. Rapid filling and emptying of the reactor system is also possible.
• In addition to the selectable process parameters - speed, tubing diameter, flow quantity display, dosing volume, interval dosing and break times - the pump conveying characteristics are stored in the program. Thanks to the analogue and digital (RS 232) interfaces, processes can be automated.
• All media is conveyed with a control accuracy of ±0.5% at a speed of 24 — 600 rpm. An optional foot switch can be connected for dosing by foot pressure.

Work space in laboratories must be used efficiently. The Omnia xs system frees up space on the lab bench and makes work more efficient.

Despite the extremely compact design in xs format, the system works in a resource-saving and completely autonomous way. Accessories such as a leakage sensor, pressure reducer, and pre-treatment cartridges are already integrated in the compact housing. This saves space in the laboratory and also ensures exceptional operational and occupational safety.
OmniaTap xs basic is the ideal system when both pure water and ultrapure water are required, but in relatively small amounts. The ability to provide both types from a single system results from the combination of ultramodern purification technologies. These also make it possible to connect the system directly to tap water. A press on the dispenser button activates dispensing of ultrapure water type I via the digital dispenser control. The recirculation of the pure water held in the installed 7 litre tank keeps it permanently at type II quality. The pure water tank provides a second optional outlet for feeding downstream end users. A pure water storage tank is required to operate the OmniaTap devices, which can be ordered separately.

Features
• OptiFill basic dispenser is standard
• Spent filters are simply and quickly exchanged
• Leakage sensor is standard
• Ready-to-use, including filter cartridges

Pure and ultrapure water from the super slim Omnia xs compact system with intuitive basic dispenser.
Work space in laboratories must be used efficiently. The Omnia xs system frees up space on the lab bench and makes work more efficient.
Despite the extremely compact design in xs format, the system works in a resource-saving and completely autonomous way. Accessories such as a leakage sensor, pressure reducer, and pre-treatment cartridges are already integrated in the compact housing. This saves space in the laboratory and also ensures exceptional operational and occupational safety.
When your need is for highest quality pure water that fulfils the demands of analytical and life science laboratory requirements, then one of these OmniaPure systems will be the right choice for you. The incorporated pre-treatment constantly ensures the reliability of your experimental results and reduces running costs.
Features
• OptiFill basic dispenser is standard
• Spent filters are simply and quickly exchanged
• Leakage sensor is standard
• Integrated pressure reducer is standard
• Very space saving
• Ready-to-use, including filter cartridges
